Nexperia 100 V 1 A Rectifier & Schottky Diode Trench MEGA Schottky 2-Pin SOD-123W PMEG100T10ELRX
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Model | PMEG100T10ELRX |
| Mount Type | Surface |
| Series | PMEG100T10ELR |
| Maximum Operating Temperature | 175°C |
| Package Type | SOD-123W |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Diode Configuration | Single |
| Rectifier Type | Trench MEGA Schottky |
| Peak Non-Repetitive Forward Surge Current Ifsm | 40A |
| Maximum Forward Voltage Vf | 750mV |
| Peak Reverse Recovery Time trr | 11.5ns |
Key Features
- This diode integrates Trench MEGA Schottky technology for high efficiency.
- It offers a low forward voltage of 750 mV and low leakage current for energy savings.
- The device supports a wide operating temperature range from -55°C to 175°C.
- Peak surge current capability reaches up to 40 A for transient conditions.
- Designed for surface mount applications in compact electronic circuits.
- Its fast recovery time of 11.5 ns enhances switching performance.
- Meets automotive AEC-Q101 standard for reliability.
Product Description
Nexperia PMEG100T10ELRX Rectifier & Schottky Diode is a high efficiency, low leakage current semiconductor device designed for surface mount applications. Encapsulated in a CFP3 (SOD-123W) small and flat lead plastic package, this Schottky barrier rectifier leverages Trench MEGA technology to achieve low forward voltage and minimal reverse current.
Its maximum continuous forward current is rated at 1 A with a peak reverse repetitive voltage of 100 V, suitable for a wide range of power electronic circuits. The diode demonstrates a low maximum forward voltage of 750 mV, which contributes to reduced power losses and improved energy efficiency in DC-to-DC converters and LED lighting systems.
Designed for demanding environments, it supports a minimum operating temperature of -55°C and a maximum operating temperature of 175°C. The device’s peak non-repetitive forward surge current can reach 40 A, addressing transient surges effectively without damage.
The fast recovery time of 11.5 ns enhances switching speed, making it ideal for switch mode power supplies, freewheeling diodes, reverse polarity protection, and OR-ing circuits. This diode meets the automotive AEC-Q101 standard, ensuring reliability in automotive and industrial applications.
Low forward voltage reduces conduction losses. Low leakage current provides higher efficiency. High power capability due to clip-bonding technology. Small and flat lead surface-mounted plastic package. Suitable for LED lighting and DC-to-DC conversion circuits.
Reverse polarity protection in sensitive electronic applications. Compliant with automotive quality standards.
This rectifier and Schottky diode is suitable for industrial, automotive, telecommunications, and power supply applications requiring efficient switching and durability. It is supplied on a reel for easy automated assembly and manufacturing efficiency.
Explore EnvMart’s semiconductor range for compatible devices and accessories to enhance your electronic designs and manufacturing workflows.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for the PMEG100T10ELRX diode is rated at 1 A.
This diode has a peak reverse repetitive voltage of 100 V.
The maximum forward voltage drop for this model is 750 mV.
It supports an operating temperature range from -55°C to 175°C.
The diode can handle a peak non-repetitive forward surge current of up to 40 A.
The PMEG100T10ELRX is encapsulated in a SOD-123W package type.
This diode meets the automotive AEC-Q101 standard for reliability.
The peak reverse recovery time for this diode is 11.5 ns.
It is designed for surface mount applications.
This diode is suitable for applications in LED lighting, DC-to-DC converters, and reverse polarity protection.
This model has a single diode configuration.
The country of origin for this diode is India.
