Vishay Zener Diode 37.19 V, 500 mW, Surface Mount 2-Pin DO-219AC PLZ39C-HG3_A/H

Name: Vishay Zener Diode 37.19 V, 500 mW, Surface Mount 2-Pin DO-219AC PLZ39C-HG3_A/H
Brand: Vishay
SKU: 110934
Price: 0.07 USD
Availability: InStock



Category Zener Diodes Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Height	0.6mm
Length	2.5mm
Model	PLZ39C-HG3_A/H
Mount Type	Surface
Series	PLZ
Maximum Operating Temperature	150°C
Package Type	DO-219AC (MicroSMF)
Minimum Operating Temperature	-55°C
Pin Count	2
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	200nA
Nominal Zener Voltage Vz	37.19V
Zener Type	General Purpose
Maximum Zener Impedance	85Ω

Key Features

This diode features a nominal Zener voltage of 37.19 V for stable operation.
It supports maximum power dissipation of 500 mW suitable for low power applications.
Mount type is surface mount with a compact DO-219AC (MicroSMF) package.
The device exhibits low leakage current and excellent stability for consistent performance.
Operating temperature range is from -55°C to 150°C, ensuring robust use under harsh conditions.
Pin count is 2 with a single diode element configuration per chip.
Test current is rated at 5 mA with a maximum Zener impedance of 85 Ω.
It complies with IEC 61760-1, RoHS, IEC 61000-4-2, and is automotive grade with AEC-Q101 certification.

Product Description

The Vishay PLZ39C-HG3_A/H is a silicon planar Zener diode specially designed for voltage regulation applications requiring precise voltage stabilization and low power dissipation up to 500 mW.

This Zener diode features a nominal voltage of 37.19 V and comes in a low-profile MicroSMF (DO-219AC) surface mount package measuring 2.5 mm in length and 0.6 mm in height. It offers excellent stability, low leakage current, and high reliability even in demanding environments.

Ideal for use in industrial electronics, automotive circuits, HVAC systems, laboratory power supplies, and precision voltage reference applications, this diode operates effectively in temperatures ranging from -55°C to 150°C, meeting stringent automotive AEC-Q101 standards.

The device has a maximum Zener impedance of 85 Ω at a test current of 5 mA, ensuring steady voltage regulation under normal operating conditions. It is fully compliant with IEC 61760-1 and RoHS directives, and withstands ESD as per IEC 61000-4-2 standards, making it suitable for advanced electronics manufacturing and assembly via wave or reflow soldering.

Nominal Zener voltage of 37.19 V for precision voltage regulation. 500 mW power dissipation rating for low power handling. Surface mount 2-pin DO-219AC MicroSMF package supports compact electronic designs. Low leakage current and robust stability enhance device longevity.

Wide operating temperature range from -55°C to 150°C. Certified automotive grade with AEC-Q101 qualification. Compliant with IEC 61760-1, RoHS, and IEC 61000-4-2 standards. Small physical footprint ideal for high-density circuit boards.

This Vishay Zener diode is suited for use in industrial, automotive, laboratory, and commercial semiconductor applications for voltage stabilization and protection circuits. Its surface mount design allows for easy integration into automated PCB assembly processes.
