TDK Shielded Wirewound Surface Mount Inductor 100 μH ±20% 800 mA 5mm x 4.5mm x 5.3mm VLS5045EX-101M-H
Specifications
| Country of Origin | Korea |
|---|---|
| Brand | TDK |
| Height | 4.5mm |
| Length | 5mm |
| Model | VLS5045EX-101M-H |
| Depth | 5.3mm |
| Packaging | Tape & Reel |
| Series | VLS-EX-H |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 100μH |
| Standards/Approvals | RoHS |
| Package/Case | 5045 |
| Maximum DC Current | 800mA |
| Maximum DC Resistance | 754mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Inductor Construction | Shielded |
| Automotive Standard | AEC-Q200 |
Key Features
- Constructed with a ferrite core providing excellent magnetic shielding.
- Compact package size of 5mm length, 4.5mm height, and 5.3mm depth.
- Inductance tolerance of plus or minus 20 percent at 100 kHz frequency.
- Supports automotive standard AEC-Q200 for reliable automotive applications.
- Maximum DC resistance of 754 milliohms ensuring low power loss.
- Operating temperature range from minus 40 to 125 degrees Celsius.
- Surface mount termination style for high-density PCB assembly.
- Provided in tape and reel packaging for automated manufacturing processes.
Product Description
TDK VLS5045EX-101M-H is a shielded wirewound surface mount inductor featuring a ferrite core, designed for demanding automotive and industrial electronics. This inductor delivers an inductance of 100 microhenries with a tolerance of ±20% at 100 kHz, supporting a maximum DC current of 800 mA.
The compact 5045 package offers dimensions of 5 mm length, 4.5 mm height and 5.3 mm depth, making it suitable for tight circuit board layouts. Constructed with high magnetic shielding, this component minimizes electromagnetic interference, optimized via ferrite magnetic material and wire wound design.
It complies with automotive standard AEC-Q200, ensuring reliability in applications such as electronic power steering, airbags, ECMs, ABS, and headlight systems. The inductor features a maximum DC resistance of 754 milliohms, contributing to high efficiency power circuits.
Surface mount termination style and tape & reel packaging facilitate automated assembly in volume production environments. Excellent magnetic shield from ferrite core and shielded wirewound construction. Compact 5045 case suitable for high-density mounting.
Automotive-grade AEC-Q200 compliance for safety-critical systems. Wide operating temperature range from -40°C to 125°C. Manufactured in Korea ensuring high-quality standards. This inductor is ideal for industrial, automotive electronics, power management systems, and other commercial applications demanding robust and compact inductors.
Explore more Surface Mount Inductors and electronic components on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 100 microhenries (μH) with a tolerance of ±20% at a frequency of 100 kHz.
The maximum DC current rating for this inductor is 800 mA.
The dimensions of this unit are 5 mm in length, 4.5 mm in height, and 5.3 mm in depth.
It operates within a temperature range of -40°C to 125°C.
This inductor features a surface mount termination style, suitable for high-density PCB assembly.
The maximum DC resistance is 754 milliohms (mΩ), contributing to low power loss.
Yes, it complies with the automotive standard AEC-Q200, ensuring reliability in automotive applications.
It is provided in tape and reel packaging, facilitating automated manufacturing processes.
The core material of this inductor is ferrite, which provides excellent magnetic shielding.
This inductor is suitable for applications in electronic power steering, airbags, ECMs, ABS, and headlight systems.
This inductor is manufactured in Korea, ensuring adherence to high-quality standards.
It belongs to the VLS-EX-H series of inductors.
