Samtec ESQ Series Vertical Through Hole PCB Socket, 40-Contact, 2 Row, 2.54 mm Pitch, 5.7A, 515V ESQ-120-49-G-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 515V |
| Brand | Samtec |
| Orientation | Vertical |
| Current | 5.7A |
| Model | ESQ-120-49-G-D |
| Mount Type | Through Hole |
| Housing Material | Black Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | ESQ |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Socket |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 40 |
| Connector System | Board-to-Board |
| Contact System | Tiger Buy™ |
Key Features
- Constructed with black glass filled polyester housing for durability.
- Features phosphor bronze contacts with gold plating for reliable conductivity.
- Supports current rating of 5.7A and voltage of 515V.
- Designed for through-hole vertical mounting with solder termination.
- Operates within temperature range of -55°C to 125°C for industrial applications.
- Employs Tiger Buy™ contact system ensuring consistent performance.
- Ideal for single, double, and triple row applications up to 108 pins.
- Meets board-to-board connector system standards for PCB sockets.
Product Description
Samtec ESQ-120-49-G-D is a high-quality vertical through-hole PCB socket featuring 40 contacts arranged in 2 rows with 2.54 mm pitch. Designed with a black glass filled polyester housing, it provides excellent durability and mechanical stability in electronic assemblies.
Each contact is made of phosphor bronze and plated with gold to ensure reliable electrical conductivity and corrosion resistance. The socket supports a current rating of 5.7A and voltage rating of 515V, making it suitable for demanding industrial and electronic applications.
It is engineered for through-hole mounting with solder termination, allowing strong mechanical retention on printed circuit boards. Its operational temperature range from -55°C to 125°C makes it versatile for a variety of environments including industrial automation, telecommunications, instrumentation, and power electronics.
The ESQ series employs the Tiger Buy™ contact system which provides low insertion force and dependable mating cycles, enhancing the longevity of connections. The product supports single, double, and triple row configurations with up to 108 pins, making it adaptable to a broad range of design requirements.
Constructed with black glass filled polyester for strength and insulation. Phosphor bronze gold-plated contacts ensure superior electrical performance. Rated for 5.7A current and 515V voltage for safe operation. Through-hole vertical orientation ideal for board-to-board connections.
Wide temperature tolerance of -55°C to 125°C suits industrial applications. Tiger Buy™ contact system offers low insertion force. Supports up to 108 pins in multi-row configurations for flexible design.
This Samtec ESQ series PCB socket is widely used in industrial electronics, instrumentation, telecommunications, and manufacturing sectors where reliable and robust PCB connections are essential. The socket is a vital component in systems requiring consistent electrical integrity and mechanical strength.
Explore more connectors and electronic components from Samtec and similar products in our PCB Sockets category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The PCB socket supports a current rating of 5.7A and a voltage rating of 515V.
This model features a pitch of 2.54 mm and has 40 contacts arranged in 2 rows.
The housing is made of black glass filled polyester, and the contacts are made of phosphor bronze with gold plating for conductivity.
It operates within a temperature range of -55°C to 125°C, making it suitable for various industrial applications.
The socket features through-hole termination with solder for secure mounting on printed circuit boards.
It employs a board-to-board connector system, which is suitable for various electronic applications.
This PCB socket is designed for vertical mounting, allowing for efficient use of space in electronic assemblies.
This model utilizes the Tiger Buy™ contact system, which offers low insertion force and reliable mating cycles.
The dimensions are not explicitly provided, but it is designed to fit standard 2.54 mm pitch applications.
It is widely used in industrial electronics, telecommunications, instrumentation, and manufacturing sectors.
The country of origin for this product is India.
