Nexperia 1 A NPN Low Saturation Voltage Transistor 180 V 3-Pin SOT-23 PBHV8118T,215

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 1 A NPN Low Saturation Voltage Transistor 180 V 3-Pin SOT-23 PBHV8118T,215

Name: Nexperia 1 A NPN Low Saturation Voltage Transistor 180 V 3-Pin SOT-23 PBHV8118T,215
Brand: Nexperia
SKU: 107340
Price: 0.27 USD
Availability: InStock



Category Bipolar Transistors Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1.1mm
Length	6.7mm
Model	PBHV8118T,215
Width	7.3mm
Mount Type	Surface
Series	PBHV8118T
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-55°C
Standards/Approvals	RoHS
Pin Count	3
Maximum Collector Emitter Voltage Vceo	180V
Minimum DC Current Gain hFE	100
Transistor Polarity	NPN
Maximum Emitter Base Voltage VEBO	6V
Maximum Collector Base Voltage VCBO	400V
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	300mW
Maximum DC Collector Current Idc	1A
Transistor Configuration	Single
Maximum Transition Frequency ft	100MHz

Key Features

Maximum collector current of 1 ampere for robust switching performance.
Collector-emitter voltage rating of 180 volts ensures high voltage tolerance.
Compact 3-pin SOT-23 surface mount package for space-saving designs.
High current gain minimum of 100 for efficient amplification.
Low power dissipation up to 300 milliwatts to reduce heat generation.
Wide operating temperature range from -55°C to 150°C for reliability.
Transition frequency of 100 MHz suitable for high-speed switching.
Conforms to RoHS standards and automotive grade AEC-Q101 certified.

Product Description

Nexperia PBHV8118T,215 is a 1 A NPN bipolar junction transistor designed for low saturation voltage and high efficiency in switching and digital applications. Housed in a compact 3-pin SOT-23 surface mount package, this transistor offers a maximum collector emitter voltage of 180 V and a maximum collector current rating of 1 A.

The device exhibits a minimum DC current gain (hFE) of 100 and a maximum power dissipation of 300 mW, providing efficient performance with reduced heat generation. It operates reliably across a wide temperature range of -55°C to 150°C and has a maximum transition frequency (ft) of 100 MHz, making it suitable for high-speed switching circuits and signal amplification.

Its compact dimensions (height 1.1 mm, length 6.7 mm, width 7.3 mm) allow it to fit in space-constrained designs, while the transistor features a typical NPN polarity and single configuration packaged for surface mount applications.

This transistor is compliant with RoHS environmental standards and meets the automotive standard AEC-Q101, ensuring quality and reliability in automotive and industrial environments.

Maximum collector current: 1 A. Maximum collector-emitter voltage: 180 V. Surface mount SOT-23 package. High current gain minimum of 100. Maximum power dissipation of 300 mW. Operating temperature from -55°C to 150°C. Transition frequency of 100 MHz.

RoHS compliant and automotive grade AEC-Q101 certified. Compact dimensions for efficient PCB layout.

This transistor is suitable for industrial, automotive, and consumer electronics applications that require efficient switching and low saturation voltage. It is ideal for signal amplification, switching regulators, and digital circuit interfaces.
