TDK Standard Metal Oxide Varistor 500 pF 25 A Clamping 2970 V B72210S0131K101
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 12mm |
| Brand | TDK |
| THICKNESS | 4.2mm |
| Length | 39.5mm |
| Model | B72210S0131K101 |
| Depth | 4.2mm |
| Mount Type | Lead |
| Series | Standard |
| Energy Rating | 1J |
| Maximum Operating Temperature | 85°C |
| Capacitance | 500pF |
| Minimum Operating Temperature | -40°C |
| Maximum dc Voltage | 1465V dc |
| Standards/Approvals | CSA, VDE, UL, IEC, CQC |
| Pin Count | 2 |
| Lead Pitch | 7.5mm |
| Maximum AC Voltage | 1100V ac |
| Clamping Voltage VC | 2970V |
| Clamping Current | 25A |
| Maximum Surge Current | 2.5kA |
| Varistor Voltage | 205 V |
Key Features
- Standard series epoxy-coated MOV with tinned copper leads.
- Rated for surge current of 2.5 kA (8/20 µs waveform).
- Clamping voltage of 2970 V and clamping current of 25 A.
- Capacitance of 500 pF suitable for high-frequency applications.
- Wide operating temperature range from -40°C to 85°C.
- Lead pitch of 7.5 mm for standard PCB mounting.
- Non-automotive type device designed for robust industrial usage.
Product Description
TDK B72210S0131K101 Standard Metal Oxide Varistor is a high-performance surge protection component designed for electronic circuits. It features a capacitance of 500 pF, a clamping current rating of 25 A, and a clamping voltage of 2970 V, making it ideal for protecting sensitive electronics from voltage transients.
This metal oxide varistor has tinned copper wire leads and a ceramic body coated with epoxy resin to ensure durability and reliable electrical insulation. It is part of the standard series with a lead mounting type and is rated for maximum AC voltage of 1100 V and maximum DC voltage of 1465 V.
The varistor can handle surge currents up to 2.5 kA with an energy rating of 1 J, rated with an 8/20 microsecond surge waveform and a 2 ms energy duration. It has a diameter of 12 mm, length of 39.5 mm, thickness and depth of 4.2 mm, and a lead pitch of 7.5 mm. Operating temperature ranges from -40°C to 85°C ensuring versatility in various industrial and commercial applications.
This product carries multiple international approvals including CSA, VDE, UL, IEC, and CQC ensuring compliance with global safety and quality standards.
It is commonly used in electronics, power distribution, surge protection in industrial and commercial equipment, and various electrical assemblies where voltage spike suppression is required.
Standard series epoxy-coated MOV with tinned copper leads. Surge current rating of 2.5 kA (8/20 µs waveform). Clamping voltage of 2970 V and clamping current of 25 A. Capacitance of 500 pF suitable for high-frequency applications.
Wide operating temperature range from -40°C to 85°C. Multiple international safety approvals: CSA, VDE, UL, IEC, CQC. Lead pitch of 7.5 mm for standard PCB mounting. Non-automotive type device designed for robust industrial usage.
Explore the Varistor category at EnvMart for more surge protection components and electrical safety solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The clamping voltage of this model is 2970 V, which helps protect sensitive electronics from voltage transients.
It is rated for a maximum surge current of 2.5 kA with an 8/20 µs waveform.
This unit has a capacitance of 500 pF, making it suitable for high-frequency applications.
The varistor has a diameter of 12 mm, a length of 39.5 mm, and a thickness of 4.2 mm.
It operates within a temperature range of -40°C to 85°C, allowing for use in various industrial environments.
The maximum AC voltage rating is 1100 V, and the maximum DC voltage rating is 1465 V.
This model uses a lead mounting type with a lead pitch of 7.5 mm, suitable for standard PCB mounting.
It carries multiple international approvals including CSA, VDE, UL, IEC, and CQC, ensuring compliance with global safety standards.
The energy rating is 1 J, which indicates the amount of energy it can absorb during a surge event.
It is commonly used in electronics, power distribution, and surge protection for industrial and commercial equipment.
This unit has a pin count of 2, which is typical for lead-mounted components.
The varistor voltage is 205 V, which is the voltage at which the varistor begins to conduct current.
