onsemi 22 V 500 mW Surface Mount Zener Diode Single 5% Tolerance 2-Pin SOD-123 MMSZ5251BT1G

Free Delivery in India | Lowest Global Shipping Charges

onsemi 22 V 500 mW Surface Mount Zener Diode Single 5% Tolerance 2-Pin SOD-123 MMSZ5251BT1G

Name: onsemi 22 V 500 mW Surface Mount Zener Diode Single 5% Tolerance 2-Pin SOD-123 MMSZ5251BT1G
Brand: onsemi
SKU: 106354
Price: 0.04 USD
Availability: InStock



Category Zener Diodes Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.35mm
Length	3.86mm
Model	MMSZ5251BT1G
Mount Type	Surface
Maximum Operating Temperature	150°C
Package Type	SOD-123
Minimum Operating Temperature	-55°C
Standards/Approvals	RoHS
Pin Count	2
Number of Elements per Chip	1
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	5.6mA
Maximum Reverse Leakage Current	100nA
Nominal Zener Voltage Vz	22V
Zener Type	Voltage Regulator
Maximum Zener Impedance	29Ω
Surface Mount case	SOD-123
Diodes Inc, 22V Zener Diode 5% 500 mW SMT 2-Pin SOD-123Brand	DiodesZetex

Key Features

Single diode configuration with 2-pin layout for easy mounting.
Nominal Zener voltage of 22 V with ±5% tolerance ensures voltage regulation.
Maximum power dissipation rating of 500 mW supports low power applications.
Temperature operating range from -55°C to +150°C suitable for diverse environments.
Maximum Zener impedance of 29 Ω and reverse leakage current limited to 100 nA.
Compliance with RoHS standards for environmental safety.
Test current rating at 5.6 mA confirms operational parameters.

Product Description

onsemi MMSZ5251BT1G is a high-quality Zener diode engineered for voltage regulation in various low power electronic applications. Housed in a surface mount SOD-123 package, it offers reliable performance with a nominal Zener voltage of 22 V and maximum power dissipation of 500 mW.

The diode is configured as a single element with 2 pins, facilitating easy PCB mounting. Its compact dimensions (1.35 mm height and 3.86 mm length) enable use in space-constrained circuit designs common in industrial and consumer electronics.

Operating across a wide temperature range (-55°C to 150°C), this diode meets robustness requirements for harsh environments. It features a maximum Zener impedance of 29 Ω and low reverse leakage current of 100 nA, thereby contributing to circuit stability and efficiency.

Tested at a current of 5.6 mA, the MMSZ5251BT1G assures precise voltage regulation with a tolerance of ±5%. The component complies with RoHS for environmental safety, making it suitable for modern electronic manufacturing standards.

Single diode configuration with 2-pin surface mount package. 22 V nominal Zener voltage with ±5% tolerance for accurate regulation. Supports up to 500 mW power dissipation in compact SOD-123 format. Wide operating temperature range from -55°C to +150°C.

Low maximum reverse leakage current of 100 nA ensures minimal losses. Maximum Zener impedance of 29 Ω enhances voltage stability. RoHS compliant ensuring environmental and safety standards. Ideal for semiconductor applications requiring voltage regulation in compact boards.

This Zener diode is widely used in electronic, industrial, and communications equipment for voltage regulation and protection. Its surface mount design integrates seamlessly into automated assembly lines and advanced manufacturing processes. Choose onsemi MMSZ5251BT1G for reliable and efficient voltage regulation in your electronic design projects.
