| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.11mm |
| Length | 3.04mm |
| Model | MMBZ5235BLT1G |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation Pd | 300mW |
| Diode Configuration | Single |
| Test Current It | 20mA |
| Maximum Reverse Leakage Current | 3μA |
| Nominal Zener Voltage Vz | 6.8V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 5Ω |
| Surface Mount case | SOT-23 |
onsemi MMBZ5235BLT1G is a precision single Zener diode designed to deliver a nominal Zener voltage of 6.8 V with a power dissipation rating of 300 mW. Packaged in a surface mount SOT-23 case with 3 pins, this component is optimized for compact and automated electronic assemblies.
The device maintains voltage regulation with a tight tolerance of ±5%, making it suitable for voltage stabilization, reference voltage generation, and overvoltage protection applications in electronic circuits.
It supports a wide operating temperature range from −65°C to 150°C, ensuring reliable performance in demanding industrial, automotive, and commercial environments. The test current is rated at 20 mA with a maximum Zener impedance of 5 Ω and minimal reverse leakage current of 3 μA.
The diode's compact dimensions of 3.04 mm length and 1.11 mm height facilitate space-saving PCB layouts where small form factors are essential. The device is RoHS compliant, aligning with modern environmental guidelines for electronic components.
Typical applications include industrial automation systems, power electronics, signal conditioning circuits, voltage regulation, and electronics manufacturing requiring high reliability and voltage precision. The surface mount design facilitates efficient mass production and assembly.
This diode offers a precise voltage regulation function with a ±5% tolerance. It supports a maximum operating temperature up to 150°C for demanding applications. Designed with 3-pin surface mount configuration suitable for automated PCB assembly.
Maximum reverse leakage current is low at 3 μA ensuring minimal power loss. The maximum Zener impedance of 5 Ω ensures stable performance under test current of 20 mA. The diode operates reliably down to −65°C, covering wide temperature ranges.
Compact dimensions: length 3.04 mm and height 1.11 mm enable space-saving designs. RoHS compliant ensuring environmentally safe manufacturing standards. Explore the range of semiconductor components for industrial and commercial electronics on EnvMart for reliable sourcing and technical data.
