Hirose DF13 Series Straight Surface PCB Header 8 Contacts 1.25 mm Pitch 1 Row Shrouded
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 150V |
| Brand | Hirose |
| Orientation | Straight |
| Current | 1A |
| Model | DF13 |
| Mount Type | Surface |
| Housing Material | Polyamide |
| Contact Material | Copper Alloy |
| Series | DF13 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -35°C |
| Number of Rows | 1 |
| Pitch | 1.25mm |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Compact and miniaturised design suited for space saving applications.
- Single row configuration with gold-plated copper alloy contacts for reliable connectivity.
- Durable polyamide housing featuring scoop proof box structure and polarization slots.
- Friction locking mechanism ensures a secure mating connection.
- Supports surface mount technology with metal fittings to prevent solder peeling.
- Operating temperature range from -35°C to 85°C for diverse environmental conditions.
- Equipped with PCB mounting bosses for accurate placement and alignment on printed circuit boards.
- Widely used in portable devices, digital cameras, LCD displays, navigation systems, and measurement instruments.
Product Description
Hirose DF13C-8P-1.25V(51) PCB Header is a single row, straight orientation connector designed for surface PCB mounting applications. It features 8 gold-plated copper alloy contacts with a 1.25 mm pitch, housed in a durable polyamide casing that includes a scoop proof box structure and polarization slots to prevent incorrect insertion. This series supports wire-to-board connection systems and offers a compact, miniaturized design ideal for high density requirements.
The shrouded design with friction locking mechanism guarantees secure mating connection and mechanical stability. Its robust construction supports an operating temperature range from -35°C to 85°C, making it suitable for diverse industrial and consumer electronic environments. Metal fittings on SMT versions ensure reliable attachment and reduce solder peeling, while PCB mounting bosses aid in precise alignment on circuit boards.
This PCB header is rated for 150 V and 1 A current, designed specifically for space-constrained portable devices such as digital cameras, LCD displays, digital video recorders, car navigation units, access control systems, and measurement devices. The product is manufactured in Japan, delivering consistent quality expected from Hirose connectors.
Compact and miniaturised design for efficient space usage. Polarization slots and scoop proof housing prevent misinsertion. Reliable gold-plated copper alloy contacts for optimum electrical performance. Durable polyamide housing suitable for industrial and consumer electronics.
Friction locking mechanism ensures secure mating connection. Supports automated pick and place mounting for mass production. Metal fittings improve SMT attachment strength and solder reliability. Suitable for various digital and measuring electronic applications.
Explore more Hirose PCB connector solutions on EnvMart for your electronic design needs.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Hirose DF13 Series PCB header is rated for a voltage of 150V.
This model has a current rating of 1A.
The contacts on this PCB header have a pitch size of 1.25 mm.
The housing is made of polyamide, and the contacts are composed of gold-plated copper alloy.
It operates within a temperature range of -35°C to 85°C.
This PCB header features 8 contacts.
This connector supports surface mounting.
The Hirose DF13 Series PCB header is designed as shrouded.
The connector has a straight orientation.
It utilizes a wire-to-board connector system.
The housing includes polarization slots and a scoop proof box structure to prevent misinsertion.
The Hirose DF13 Series PCB header is manufactured in Japan.
