Wurth Elektronik 6 Way Straight Male FPC Connector, 1 mm Pitch, Surface Mount, Solder Pin Termination, 125V, 1A 68610614422
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 125V |
| Brand | Wurth Elektronik |
| Orientation | Straight |
| Current | 1A |
| Mount Type | Surface |
| Housing Material | Polyphenylene Sulphide |
| Contact Material | Phosphor Bronze |
| Series | 686 |
| Termination Type | Solder Pin |
| Maximum Operating Temperature | 85°C |
| Sub Type | Wire-to-Board |
| Minimum Operating Temperature | -25°C |
| Number of Rows | 1 |
| Pitch | 1mm |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Connector Gender | Male |
| Insertion Force | ZIF |
| Contact Position | Bottom |
Key Features
- Supports 6 contacts with phosphor bronze material for durability.
- Operates at 125V and conducts current up to 1A.
- Features a Zero Insertion Force (ZIF) bottom contact for ease of use.
- Constructed with polyphenylene sulphide housing supporting high flammability rating UL94-V0.
- Designed for a maximum operating temperature of 85°C and minimum of -25°C.
- Ensures secure connectivity with a locking mechanism and straight orientation.
- Capable of 25 mating cycles, suitable for compact electronic applications.
- Contact plating is tin over nickel for corrosion resistance.
Product Description
Wurth Elektronik 68610614422 is a 6 Way Straight Male FPC Connector designed for electronic assemblies requiring high reliability and compactness. It features a precise 1 mm pitch and a surface mount style with solder pin termination, making it suitable for PCB connector applications in various electronic devices.
This series 686 connector supports a current rating of 1 ampere and a voltage rating of 125 volts, providing stable electrical performance. The connector employs phosphor bronze contacts with tin over nickel plating for enhanced durability and corrosion protection, along with a polyphenylene sulphide housing material that meets UL94-V0 flammability standards.
The contact position is at the bottom with a Zero Insertion Force (ZIF) design, reducing mechanical stress during assembly and ensuring easy mating and unmating. It includes a locking mechanism to secure connections and features a straight orientation with a single row of 6 contacts. This makes it ideal for tightly packed electronics and compact devices.
The product can operate within a temperature range from -25°C to 85°C, ensuring reliable function in diverse environmental conditions. It is rated for 25 mating cycles, balancing longevity and performance for industrial or commercial electronic applications.
Supports 6 phosphor bronze contacts with tin over nickel plating. Surface mount with solder pin termination and bottom contact position. Zero Insertion Force (ZIF) design for ease of use. Polyphenylene sulphide housing with UL94-V0 flammability rating.
Operating temperature range: -25°C to 85°C. Locking mechanism ensures secure connection. Suitable for compact and compact electronic applications.
This FPC connector is applicable in industrial electronics, power and connectors sectors, especially in assemblies requiring reliable wire-to-board connections. Its robust design and compliance with UL standards make it suitable for laboratory, manufacturing, and electronic repair environments.
Explore a wide range of FPC Connectors and other electronic components at EnvMart for your design and production needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The voltage rating of this connector is 125V.
It can conduct a current of up to 1A.
The pitch of this model is 1 mm.
The housing is made of polyphenylene sulphide, and the contacts are made of phosphor bronze with tin over nickel plating.
It operates within a temperature range of -25°C to 85°C.
This connector supports 6 contacts.
It features a solder pin termination type.
The orientation of this connector is straight.
It is rated for 25 mating cycles.
Yes, it includes a locking mechanism to ensure secure connectivity.
It employs a Zero Insertion Force (ZIF) design for ease of use.
It is suitable for industrial electronics, power and connectors sectors, particularly in assemblies requiring reliable wire-to-board connections.
