TDK Wirewound Shielded Surface Mount Inductor 220μH ±20/±30% 1.2A Idc Ferrite Core SLF12565T-221M1R0-PF
Specifications
| Country of Origin | India |
|---|---|
| Brand | TDK |
| Height | 6.5mm |
| Length | 12.5mm |
| Model | SLF12565T-221M1R0-PF |
| Depth | 7.5mm |
| Packaging | Taping |
| Series | SLF |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 220μH |
| Standards/Approvals | RoHS |
| Package/Case | 12565 |
| Maximum DC Current | 1.2A |
| Maximum DC Resistance | 273mΩ |
| Inductance Tolerance | ±20/±30 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
Key Features
- Magnetically shielded design for EMC reduction.
- Inductance tolerance of ±20/±30% ensures performance consistency.
- Constructed with ferrite core and wirewound inductor construction.
- Suitable for applications like portable telephones, personal computers, and hard disk drives.
- Surface mount termination style with taping packaging for efficient production assembly.
- Operates within temperature range of -40°C to 105°C.
- Maximum DC resistance is 273mΩ for reliable electrical characteristics.
- Low-profile package dimensions with 12.5mm length, 6.5mm height, and 7.5mm depth.
Product Description
TDK SLF12565T-221M1R0-PF Wirewound Shielded Surface Mount Inductor features a ferrite core and delivers an inductance of 220μH with a tolerance of ±20/±30%. It supports a maximum DC current of 1.2A, making it suitable for various electronic applications demanding reliable power management components.
This inductor is designed with a magnetically shielded wirewound construction, which significantly reduces electromagnetic interference (EMC), beneficial for sensitive devices such as portable telephones, personal computers, and hard disk drives. The low-profile 12565 package case and surface mount termination style make it ideal for automated assembly on printed circuit boards.
The inductor’s dimensions are compact, with a length of 12.5mm, height of 6.5mm, and depth of 7.5mm, facilitating use in space-constrained environments. It operates reliably across a wide temperature range from -40°C to 105°C, with a maximum DC resistance of 273mΩ, ensuring stable performance under various electrical loads.
The taped packaging further supports high-volume production efficiency.
Industrial use cases include electronics manufacturing, power supplies, telecommunications devices, data storage equipment, and computing hardware. This component adheres to industry standards and presents a robust solution for surface mount inductor requirements.
Magnetically shielded design for EMC reduction. Consistent inductance with ±20/±30% tolerance. Ferrite core wirewound construction for enhanced performance. Surface mount termination with taping packaging. Operating temperature range from -40°C to 105°C.
Compact 12565 package size with low profile dimensions. Maximum DC current rating of 1.2A. Low DC resistance of 273mΩ ensuring efficiency. RoHS compliant manufacturing standards. Explore more Surface Mount Inductors and electronic components at EnvMart to meet your industrial, laboratory, and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 220μH with a tolerance of ±20/±30%.
This inductor supports a maximum DC current of 1.2A.
The dimensions of this unit are 12.5mm in length, 6.5mm in height, and 7.5mm in depth.
It operates reliably within a temperature range of -40°C to 105°C.
The maximum DC resistance is 273mΩ, ensuring efficient electrical characteristics.
This inductor is constructed with a ferrite core.
The termination style of this inductor is surface mount.
It comes in taped packaging, which supports efficient production assembly.
It is suitable for applications such as portable telephones, personal computers, and hard disk drives.
Yes, this model adheres to RoHS manufacturing standards.
It features a wirewound construction, which enhances its performance.
This inductor belongs to the SLF series.
