Wurth Elektronik 411B Series PCB Terminal Block 12-Contact 5 mm Pitch Through Hole 1 Row 691411710012B

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik 411B Series PCB Terminal Block 12-Contact 5 mm Pitch Through Hole 1 Row 691411710012B

Name: Wurth Elektronik 411B Series PCB Terminal Block 12-Contact 5 mm Pitch Through Hole 1 Row 691411710012B
Brand: Wurth Elektronik
SKU: 103445
Price: 6.59 USD
Availability: InStock



Category PCB Terminal Block Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Voltage	300V ac
Brand	Wurth Elektronik
Colour	White, Grey
Orientation	Horizontal
Current	10A
Length	61.6mm
Model	691411710012B
Depth	15.25mm
Width	12.6mm
Mount Type	Through Hole
Series	411B
Number of Rows	1
Pitch	5mm
Standards/Approvals	VDE, RoHS, cULus
Number of Contacts	12
Minimum Wire Size mm²	0.5mm²
Maximum Wire Size mm²	2.1mm²
Minimum Wire Size AWG	20AWG
Maximum Wire Size AWG	14AWG

Key Features

The terminal block supports a maximum current of 10A.
It accommodates wire sizes from 0.5 mm² to 2.1 mm² and AWG 20 to 14.
Features a horizontal orientation with white and grey coloration.
Rated for 300V AC voltage operation.
Compact dimensions include a length of 61.6 mm, width of 12.6 mm, and depth of 15.25 mm.
Manufactured with compliance to VDE, RoHS, and cULus standards.
Part of the 411B series and made in China.

Product Description

Wurth Elektronik 691411710012B PCB Terminal Block is a precision-engineered electronic component designed for mounting on printed circuit boards in various industrial and commercial applications. This 12-contact terminal block features a through hole mounting style and a 5 mm pitch, making it compatible with a wide range of PCBs requiring secure, reliable electrical connections.

It supports a current rating of 10A and can handle wire sizes ranging from 0.5 mm² up to 2.1 mm², or AWG20 to AWG14, accommodating a variety of wiring requirements. The terminal block is oriented horizontally and comes in white and grey colors to facilitate easy identification and installation.

The component is rated for use up to 300V AC, ensuring suitability for many electronic circuit configurations. Its compact physical footprint with dimensions of 61.6 mm in length, 12.6 mm in width, and 15.25 mm in depth allows for efficient PCB layout design, maintaining high-density board assembly without compromise on performance.

Manufactured in China, this product conforms to several important industry standards including VDE, RoHS, and cULus, ensuring high quality, safety, and environmental compliance. The 411B series from Wurth Elektronik provides reliable terminal block solutions for electronic manufacturing, power distribution, control systems, and other industrial automation applications.

The terminal block supports a maximum current of 10A. Accommodates wire sizes from 0.5 mm² to 2.1 mm². Horizontal orientation with white and grey color coding. Rated voltage of 300V AC. Compact size with length 61.6 mm, width 12.6 mm, and depth 15.25 mm.

Conforms to VDE, RoHS and cULus standards. Manufactured in China as part of 411B series.

This product is ideal for industrial electronics, power supply design, PCB assembly, and electrical control panels. Its reliable connection system ensures easy implementation within demanding electrical environments. Browse the Electronics Components category at EnvMart for more Wurth Elektronik products and other PCB Terminal Blocks for your design needs.
