TDK Unshielded Wirewound Surface Mount Inductor with Ferrite Core 68μH ±10% 80mA 1210 Package B82422A1683K100
Specifications
| Country of Origin | India |
|---|---|
| Brand | TDK |
| Height | 2mm |
| Length | 3.2mm |
| Model | B82422A1683K100 |
| Depth | 2.5mm |
| Packaging | Tape & Reel |
| Series | B82422A*100 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Ferrite |
| Inductance | 68μH |
| Standards/Approvals | RoHS |
| Package/Case | 1210 |
| Maximum DC Current | 80mA |
| Pin Count | 2 |
| Maximum DC Resistance | 7.7Ω |
| Inductance Tolerance | ±10 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 9MHz |
| Minimum Quality Factor | 27 |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
| Mini reel surface mount inductor,68uHBrand | Epcos |
Key Features
- High quality wirewound surface mount inductor with ferrite core.
- Designed for compact 1210 package with dimensions 3.2mm x 2.5mm x 2mm.
- Maximum DC current rating of 80mA ensures stable performance.
- Suitable for automotive applications with AEC-Q200 automotive standard compliance.
- High resonance frequency of up to 9MHz for efficient signal handling.
- RoHS compliant and environmentally friendly design.
- Inductor construction ensures low DC resistance of 7.7Ω.
- Wide operating temperature range from -55°C to 125°C.
Product Description
TDK B82422A1683K100 Unshielded Wirewound Surface Mount Inductor with Ferrite Core is designed for electronics applications requiring precision inductance and compact form factor. This inductor features a 68μH inductance with a tolerance of ±10%, making it suitable for signal filtering, energy storage, and circuit tuning in industrial and automotive systems.
The device is encapsulated in a 1210 package with physical dimensions of 3.2mm length, 2.5mm depth, and 2mm height. Its wirewound construction provides a high-quality factor of 27, which ensures efficiency in high-frequency circuits up to 9MHz self-resonance frequency.
Designed to meet AEC-Q200 automotive standards, it supports reliable operation within a temperature range of -55°C to 125°C, with a maximum DC current of 80mA. The low DC resistance of 7.7Ω helps reduce power losses, making this inductor a robust component for power electronics and surface mount technology applications.
High quality wirewound Surface Mount Inductor with ferrite core. Compact 1210 package suitable for high-density PCB assemblies. Maximum DC current rating of 80mA ensures stable performance in circuits. Complies with automotive industry standards (AEC-Q200).
High resonance frequency rating of 9MHz for advanced electronic designs. RoHS compliant, ensuring environmental safety and regulatory conformity. Wide operating temperature range allowing use in harsh environments. Low DC resistance for efficient power handling and minimal heat generation.
This TDK inductor is ideal for use in consumer electronics, automotive electronics, power management circuits, industrial control systems, and other surface mount applications requiring reliable and precise inductance components.
Explore the Electronics Components category on EnvMart for more advanced inductors and passive electronic components to meet your project requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 68μH with a tolerance of ±10%.
The inductor is housed in a 1210 package with dimensions of 3.2mm in length, 2.5mm in depth, and 2mm in height.
The maximum DC current rating for this unit is 80mA, ensuring stable performance in circuits.
It has a maximum self-resonant frequency of 9MHz, making it suitable for high-frequency applications.
The operating temperature range is from -55°C to 125°C, allowing its use in various environments.
The core material of this inductor is ferrite, which contributes to its performance characteristics.
The maximum DC resistance is 7.7Ω, which helps reduce power losses in circuits.
Yes, it complies with AEC-Q200 automotive standards, making it suitable for automotive applications.
This model uses a solder termination style, which is common for surface mount components.
The inductor is packaged in tape and reel format, facilitating automated assembly processes.
The minimum quality factor is 27, indicating its efficiency in high-frequency circuits.
This inductor is manufactured in India.
