Wurth Elektronik PCB Terminal Block 2-Contact, 9.52 mm Pitch, Through Hole Mount, Horizontal Orientation, 750V 691250910002
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 750V |
| Brand | Wurth Elektronik |
| Colour | Green |
| Orientation | Horizontal |
| Current | 32A |
| Length | 19.04mm |
| Depth | 31.5mm |
| Width | 12.2mm |
| Mount Type | Through Hole |
| Series | 2509 |
| Number of Rows | 1 |
| Pitch | 9.52mm |
| Standards/Approvals | cULus, RoHS, VDE |
| Number of Contacts | 2 |
| Minimum Wire Size mm² | 0.05mm² |
| Maximum Wire Size mm² | 5.26mm² |
| Minimum Wire Size AWG | 30AWG |
| Maximum Wire Size AWG | 10AWG |
Key Features
- Features 2 electrical contacts for secure connections.
- Pitch spacing of 9.52 mm ensures compatibility with standard PCB layouts.
- Rated current of 32 amps, suitable for moderate power applications.
- Horizontal orientation and green coloration for easy identification.
- Constructed with through hole mount type for sturdy PCB attachment.
- Accepts wire sizes from 0.05 mm² to 5.26 mm² (30 to 10 AWG).
- Complies with cULus, RoHS, and VDE standards.
Product Description
Wurth Elektronik 691250910002 PCB Terminal Block is a high-quality connector designed for electronics applications on printed circuit boards. This two-contact terminal block features a 9.52 mm pitch and a through hole mount, ensuring a robust and reliable electrical connection. The horizontal orientation and green color coding facilitate easy installation and identification in complex electronic assemblies.
Rated for 32 amps and 750 volts, it supports a wide range of medium power applications. This terminal block accommodates wire sizes between 0.05 mm² and 5.26 mm² (30 AWG to 10 AWG), making it versatile for many cabling requirements. Its compact dimensions (19.04 mm length, 12.2 mm width, and 31.5 mm depth) fit standard PCB layouts, optimizing space without compromising performance.
Engineered for safety and compliance, it meets cULus, RoHS, and VDE standards, ensuring environmentally friendly and secure operation. The 2509 series terminal blocks from Wurth Elektronik are well-regarded for offering reliable wire protection and secure clamp systems, with this product representing a 2-contact, 1-row configuration in that portfolio.
This terminal block is ideal for use in electronic products, instrumentation, industrial control systems, power distribution equipment, and automation solutions. It offers peace of mind in applications requiring dependable electrical contacts on circuit boards.
Features 2 electrical contacts for secure connections. Pitch spacing of 9.52 mm ensures compatibility with standard PCB layouts. Rated current of 32 amps, suitable for moderate power applications. Voltage rating up to 750 volts for safe operation.
Horizontal orientation and green coloration for easy identification. Constructed with through hole mount type for sturdy PCB attachment. Accepts wire sizes from 0.05 mm² to 5.26 mm² (30 to 10 AWG). Compact dimensions: length 19.04 mm, width 12.2 mm, depth 31.5 mm.
Complies with cULus, RoHS, and VDE standards. Browse the Wurth Elektronik PCB Terminal Blocks category on EnvMart for a wide selection of high-quality industrial and electronic connectors.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Wurth Elektronik PCB Terminal Block has a voltage rating of 750 volts, ensuring safe operation in various applications.
It is rated for a current capacity of 32 amps, making it suitable for moderate power applications.
This model accepts wire sizes from 0.05 mm² to 5.26 mm² (30 AWG to 10 AWG), providing versatility for different cabling needs.
The terminal block has compact dimensions of 19.04 mm in length, 12.2 mm in width, and 31.5 mm in depth.
It features a pitch spacing of 9.52 mm, ensuring compatibility with standard PCB layouts.
This unit is designed for through hole mounting, providing a sturdy attachment to printed circuit boards.
The terminal block is oriented horizontally, which aids in installation and identification within electronic assemblies.
It complies with cULus, RoHS, and VDE standards, ensuring safety and environmental compliance.
This model features 2 electrical contacts for secure connections.
It is part of the 2509 series of terminal blocks from Wurth Elektronik, which are known for reliable wire protection.
The terminal block is colored green, which facilitates easy identification in complex electronic assemblies.
This unit is manufactured in India, contributing to its compliance with various standards.
