STMicroelectronics 40 V 300 mA Schottky Diode Single Configuration 3-Pin SOT-23 BAT54FILM

STMicroelectronics BAT54FILM is a Schottky diode designed for efficient power management and rapid switching in electronic circuits, equipped with a maximum continuous forward current of 300 mA and peak reverse voltage of 40 V. Its single diode configuration and compact 3-pin SOT-23 package make it suitable for surface mounting in space-constrained industrial and consumer devices.

With a low forward voltage of 900 mV and ultra-fast peak reverse recovery time of 5 ns, this diode reduces switching losses and improves overall circuit efficiency. It features a robust peak non-repetitive forward surge current rating of 1 A, ensuring durability in transient conditions.

The diode operates reliably under a wide temperature range from -40°C to 150°C, making it ideal for harsh environments often encountered in automotive, industrial automation, power supplies, and telecommunications equipment. Its minimal peak reverse current of 1 µA enhances longevity and energy efficiency by reducing leakage currents.

Dimensionally, the diode measures 2.9 mm in length, 1.3 mm in width, and 0.95 mm in height, supporting high-density PCB layouts. This product is compliant with environmental standards like RoHS, guaranteeing safe and sustainable use.

Designed for high efficiency with low forward voltage drop. Single diode configuration for versatile circuit applications. Surface mountable SOT-23 package suitable for compact electronic devices. Peak non-repetitive forward surge current of 1A ensures robustness.

Operating temperature range from -40°C to 150°C supports demanding environments. Extremely fast switching with a peak reverse recovery time of 5 ns. Compact dimensions with length 2.9 mm, width 1.3 mm, and height 0.95 mm.

Low leakage current with a peak reverse current of 1µA enhances device reliability. Ideal for power rectification, voltage clamping, and protection circuits. RoHS compliant and suitable for industrial and consumer electronic applications.

This Schottky diode is highly suited for applications in industrial automation, power management circuits, telecommunications, and automotive electronics where low forward voltage and fast switching are critical. EnvMart offers a comprehensive range of electronic components including semiconductors to support your manufacturing and repair needs.
