onsemi Surface Mount Shift Register HCT TSSOP 16-Pin MC74HCT595ADTG
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.2mm |
| Operating Voltage Range | 4.5 to 5.5 V |
| Length | 5.1mm |
| Model | MC74HCT595ADTG |
| Width | 4.5mm |
| Mount Type | Surface |
| Series | MC74HCT595A |
| Maximum Operating Temperature | 125°C |
| Package Type | TSSOP |
| Pin Count | 16 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | HCT |
| Minimum Supply Voltage | 4.5V |
| Low Input Current | 1.0 uA |
| Output Drive Capability | 15 LSTTL Loads |
| Chip Complexity | 328 FETs or 82 Equivalent Gates |
Key Features
- Includes an 8-bit shift register and 8-bit D-type latch with three-state parallel outputs.
- Provides serial data input with serial output and parallel outputs to the latch.
- Independent clock inputs for shift register and latch enable asynchronous reset for shift register.
- Compatible with SPI serial data ports on CMOS MPUs and MCUs.
- Chip complexity consists of 328 FETs or 82 equivalent gates featuring high noise immunity.
- Low input current consumption of 1.0 µA ensures energy efficiency.
- Output drive can support 15 LSTTL loads and interfaces directly with CMOS, NMOS, TTLO.
- Compact TSSOP 16-pin surface mount package with dimensions 5.1 mm length, 4.5 mm width, and 1.2 mm height.
Product Description
onsemi MC74HCT595ADTG is a surface mount shift register IC in a 16-pin TSSOP package. It consists of an 8-bit shift register combined with an 8-bit D-type latch providing three state parallel outputs, suitable for serial to parallel data conversion tasks in electronic circuits.
Operating over a voltage range of 4.5 to 5.5 V, it offers robust performance with low input current of 1.0 microampere and high noise immunity characteristic typical of CMOS devices. The device features independent clock inputs for both the shift register and the latch, as well as an asynchronous reset function for the shift register, enabling versatile control in timing critical applications.
The shift register directly interfaces with SPI serial data ports of CMOS microprocessor units (MPUs) and microcontroller units (MCUs), making it an ideal choice for embedded electronic designs. It can drive outputs equivalent to 15 LSTTL loads and compatible with CMOS, NMOS, and TTL output standards.
Physically, the MC74HCT595ADTG utilizes a compact TSSOP package with precise dimensions: length 5.1 mm, width 4.5 mm, and height 1.2 mm, facilitating high-density PCB designs. Its maximum operating temperature of 125°C suits industrial and commercial temperature environments.
Includes an 8-bit shift register and 8-bit D-type latch with three-state parallel outputs. Supports independent clock inputs and asynchronous reset for shift register. Compatible with SPI interface on CMOS MPUs and MCUs.
Output drive capability of 15 LSTTL loads. Low input current of 1.0 µA enhances power efficiency. Chip complexity comprises 328 FETs or 82 equivalent gates. Compact TSSOP 16-pin surface mount package. Operating voltage range 4.5 to 5.5 V, suitable for industrial use.
Maximum operating temperature rating 125°C.
This shift register IC is suitable for electronics and semiconductor industry applications including serial-to-parallel data conversions in microcontroller and embedded system projects, industrial automation, and logical control devices.
Explore more semiconductor and Logic ICs available at EnvMart for your electronics manufacturing and design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The operating voltage range for this model is 4.5 to 5.5 V.
The maximum operating temperature rating is 125°C.
The TSSOP package of this model has 16 pins.
It has a low input current consumption of 1.0 µA.
This model can drive outputs equivalent to 15 LSTTL loads.
It utilizes a compact TSSOP package.
The chip complexity consists of 328 FETs or 82 equivalent gates.
It is suitable for applications involving serial-to-parallel data conversions in microcontroller and embedded system projects, as well as industrial automation and logical control devices.
Yes, it features an asynchronous reset function for the shift register.
The height of the TSSOP package is 1.2 mm.
Yes, it is compatible with SPI serial data ports on CMOS microprocessor units (MPUs) and microcontroller units (MCUs).
The dimensions are 5.1 mm in length, 4.5 mm in width, and 1.2 mm in height.
