Vishay 1-Element Bi-Directional TVS Diode 1.5 kW Surface Mount 2-Pin SMC SMCJ110CA-E3/57T
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 2.42mm |
| Length | 7.11mm |
| Model | SMCJ110CA-E3/57T |
| Width | 6.22mm |
| Mount Type | Surface |
| Series | TRANSZORB TVS |
| Maximum Operating Temperature | 150°C |
| Package Type | SMC |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 177V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Single |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 122V |
| Maximum Reverse Stand-off Voltage Vwm | 110V |
| Peak Pulse Power Dissipation Pppm | 1.5kW |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 8.5A |
| Maximum Reverse Leakage Current | 1μA |
| onsemi MMT05B230, Thyristor 170VBrand | ON Semiconductor |
| onsemi MMT05B230T3G, Thyristor Surge Protector, 2-Pin DO-214AABrand | ON Semiconductor |
Key Features
- Bi-directional configuration provides protection against voltage transients in both directions.
- Rated for maximum reverse stand-off voltage of 110 V.
- Clamping voltage of 177 V with 8.5 A peak pulse current capability.
- Wide operating temperature range from -55°C to 150°C.
- Low maximum reverse leakage current of 1 μA ensures minimal power loss.
- Certified to automotive standard AEC-Q101 for high reliability.
- ESD protected transient voltage suppressor ideal for electronic circuit protection.
- Single element chip configuration in TRANSZORB® series.
Product Description
Vishay SMCJ110CA-E3/57T is a high-performance 1-element bi-directional Transient Voltage Suppressor (TVS) diode designed for surface mount applications. It features a compact 2-pin SMC package delivering robust 1.5 kW peak pulse power dissipation capacity, making it suitable for protecting sensitive electronic circuits against voltage spikes and transient surges.
This TVS diode supports bi-directional voltage transient protection with a minimum breakdown voltage (Vbr) of 122 V and a maximum reverse stand-off voltage (Vwm) of 110 V. Its clamping voltage (Vc) reaches 177 V at a test current of 1 mA, enabling it to clamp voltage spikes effectively.
Designed for demanding environments, it operates reliably across a broad temperature range from -55°C to +150°C. With a maximum peak pulse current (Ippm) of 8.5 A, and a low maximum reverse leakage current of 1 μA, this diode offers efficient and stable protection.
The device complies with the automotive AEC-Q101 standard, ensuring suitability for automotive and industrial electronics requiring high reliability. Physically, it measures 7.11 mm in length, 6.22 mm in width, and 2.42 mm in height, providing a compact footprint for PCB integration.
Applications include industrial electronics, automotive electronic modules, power supplies, and protection of communication and control equipment from transient voltage events. Bi-directional transient voltage suppression for electronics protection.
Surface mount package with compact 2-pin SMC form factor. High peak pulse power capability of 1.5 kW for surge absorption. Wide operating temperature range from -55°C to +150°C. Certified to AEC-Q101 automotive reliability standard.
Low leakage current minimizes power loss and heat generation. Robust clamping voltage and peak pulse current ratings. Ideal for industrial, automotive, and electronic circuitry transient protection. Single chip element configuration as part of TRANSZORB® series.
Tested at 1 mA test current for performance assurance. Explore our semiconductor category for more TVS Diode solutions and Vishay products designed for transient voltage protection and circuit reliability.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Vishay SMCJ110CA-E3/57T has a peak pulse power dissipation capacity of 1.5 kW.
The maximum reverse stand-off voltage for this diode is 110 V.
At a test current of 1 mA, the clamping voltage reaches 177 V.
It operates reliably across a wide temperature range from -55°C to +150°C.
The maximum peak pulse current capability of this model is 8.5 A.
The dimensions of the diode are 7.11 mm in length, 6.22 mm in width, and 2.42 mm in height.
This model is designed for surface mounting.
It is certified to the automotive standard AEC-Q101, ensuring high reliability.
The maximum reverse leakage current is 1 μA, which helps minimize power loss.
The minimum breakdown voltage (Vbr) for this model is 122 V.
This diode is suitable for applications in industrial electronics, automotive electronic modules, and power supplies, providing protection against transient voltage events.
This model features a single element configuration per chip.
