TDK 1210 Shielded Wirewound Surface Mount Inductor with Ferrite Core 68 μH ±10% 140 mA Idc Q:15 NLCV32T-680K-EF
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | TDK |
| Height | 2.2mm |
| Operating Temperature Range | - 40 to +105°C (including self-temperature rise) |
| Length | 3.2mm |
| Model | NLCV32T-680K-EF |
| Depth | 2.5mm |
| Packaging | Tape & Reel |
| Series | NLCV-EF |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 68μH |
| Standards/Approvals | RoHS |
| Package/Case | 1210 |
| Maximum DC Current | 140mA |
| Maximum DC Resistance | 3.64Ω |
| Inductance Tolerance | ±10 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 12MHz |
| Minimum Quality Factor | 15 |
| Inductor Construction | Wirewound |
Key Features
- The inductor supports a maximum DC current of 140 mA.
- It has a high quality factor of at least 15 ensuring efficient performance.
- Designed for operation between -40°C to 105°C including self-temperature rise.
- Constructed with a wirewound and moulded design for durability and shielding.
- Package size is 1210 with surface mount termination style suitable for PCB applications.
- Maximum DC resistance is 3.64 Ω ensuring low power loss.
- Maximum self-resonant frequency is 12 MHz for stable performance.
- Core material is ferrite, making it ideal for decoupling circuit applications.
Product Description
TDK NLCV32T-680K-EF is a 1210 size shielded wirewound surface mount inductor featuring a ferrite core with an inductance of 68 μH and an inductance tolerance of ±10%. It supports a maximum direct current of 140 mA, making it suitable for a variety of low-power electronics applications.
With a maximum DC resistance of 3.64 ohms and a minimum quality factor of 15, this inductor ensures efficient energy transfer and reduced signal loss. The product is designed to operate reliably within a temperature range of -40°C to 105°C, including self-temperature rise, suitable for demanding industrial environments.
The inductor is moulded and constructed with wirewound technology to provide mechanical stability and EMI shielding, ideal for use in decoupling circuits in communications and industrial equipment. The 1210 package size and surface mount termination style allow for easy integration on printed circuit boards.
Key features include a maximum self-resonant frequency of 12 MHz and compliance with RoHS environmental standards, assuring reliability and regulatory compliance. It comes packaged in tape and reel format to facilitate automated assembly processes.
This TDK surface mount inductor is predominantly used in smart meters, audio-video equipment, xDSL devices, mobile base stations, and other communication infrastructure products. The inductor supports a maximum DC current of 140 mA.
Operating temperature range is from -40°C to 105°C including self-temperature rise. Constructed using a ferrite core with wirewound technology for high performance. Provides shielding to reduce electromagnetic interference and signal noise.
Packaging is in tape and reel suitable for automated manufacturing processes. Complies with RoHS environmental standards. Has a high quality factor of 15, ensuring signal integrity. Maximum self-resonant frequency is 12 MHz for stable operation in high-frequency circuits.
Compact 1210 package size with surface mount termination for easy PCB mounting. Explore more components like this in the Surface Mount Inductors category on EnvMart to find suitable parts for advanced electronic design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 68 μH with an inductance tolerance of ±10%.
It supports a maximum DC current of 140 mA, making it suitable for low-power electronics applications.
The operating temperature range is from -40°C to 105°C, including self-temperature rise.
The maximum self-resonant frequency is 12 MHz, ensuring stable operation in high-frequency circuits.
The maximum DC resistance is 3.64 Ω, which helps in reducing power loss.
This inductor is constructed with a ferrite core, which is ideal for decoupling circuit applications.
It has a minimum quality factor of 15, ensuring efficient energy transfer and reduced signal loss.
The dimensions are 3.2 mm in length, 2.5 mm in depth, and 2.2 mm in height.
It comes packaged in tape and reel format, which facilitates automated assembly processes.
This model complies with RoHS environmental standards, assuring regulatory compliance.
It features a surface mount termination style, making it suitable for PCB applications.
It is predominantly used in smart meters, audio-video equipment, xDSL devices, and mobile base stations.
