| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.35mm |
| Length | 3.86mm |
| Model | MMSZ5240BT1G |
| Mount Type | Surface |
| Series | MMSZ52 |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-123 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation Pd | 500mW |
| Diode Configuration | Single |
| Test Current It | 20mA |
| Maximum Reverse Leakage Current | 3μA |
| Nominal Zener Voltage Vz | 10V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 17Ω |
| Surface Mount case | SOD-123 |
| Zener diode,MMSZ5240B 20mA Iz 10Vz 500mWBrand | ON Semiconductor |
onsemi MMSZ5240BT1G is a Zener diode designed for voltage regulation and protection purposes in electronic circuits. It features a single diode configuration with a nominal Zener voltage of 10 V and a maximum power dissipation of 500 mW, making it suitable for low power electronics and industrial applications.
This diode is housed in a surface mount SOD-123 package with two pins, supporting efficient PCB assembly and high-density board layouts. It operates reliably within a temperature range of -55°C to 150°C, ensuring performance stability across various industrial environments.
The diode exhibits a maximum Zener impedance of 17 ohms and a maximum reverse leakage current of 3 microamperes, contributing to its effective voltage regulation capability. It complies with RoHS standards, ensuring that it meets environmental and safety regulations for electronic components.
Its compact dimensions (length 3.86 mm, height 1.35 mm) make it ideal for space-constrained designs in industrial, electronics manufacturing, and power supply applications. Single diode configuration suitable for voltage regulation applications.
Surface mount package type SOD-123 with 2 pins for easy PCB integration. Rated maximum power dissipation of 500 mW with test current of 20mA. Operating temperature range from -55°C to 150°C ensuring reliability in harsh conditions.
Maximum Zener impedance of 17Ω and maximum reverse leakage current of 3μA for stable performance. RoHS compliant ensuring environmental safety and regulatory compliance. Compact dimensions with 3.86mm length and 1.35mm height for high-density board applications.
Part of the MMSZ52 series designed for high-density industrial applications.
This component is extensively used in industrial electronics, power supplies, communication equipment, and general-purpose voltage stabilization circuits. Its small form factor and surface mount design enable efficient automated assembly processes in manufacturing.
