Samtec TFM Series Straight Through Hole PCB Header 10 Contact 1.27 mm Pitch 2 Row Shrouded TFM-105-02-L-D-DS

Samtec TFM-105-02-L-D-DS PCB Header is a high-quality electronic component designed for reliable wire-to-board connections in industrial and commercial applications. It features 10 contacts arranged in two rows with a 1.27 mm pitch and a shrouded design to facilitate blind mating and protect the connector interface.

The housing is made from liquid crystal polymer, providing resistance to high temperatures and mechanical stress. Contacts are manufactured from phosphor bronze and plated with gold to ensure excellent electrical performance and corrosion resistance. The multi-finger beryllium copper (BeCu) contact system enhances durability and supports high cycle mating.

This through-hole mounted header uses solder termination for secure and long-lasting connections on printed circuit boards. It supports a current of 3.2A and voltage up to 250V, making it suitable for various electronics and power applications.

The operating temperature range from -55°C to 125°C covers a wide span of environmental conditions, ensuring stable operation in demanding industrial, manufacturing, and automation environments. Additional options such as screw down mounts, weld tabs, and solder nails contribute to ruggedization and secure installation.

Applications for this PCB header include industrial control systems, communication equipment, test and measurement devices, and other electronic assemblies requiring a reliable, durable connector solution that withstands high mating cycles.

Constructed with liquid crystal polymer housing for enhanced durability. Phosphor bronze contacts plated with gold provide excellent conductivity and corrosion resistance. Supports current rating of 3.2A and voltage rating of 250V.

Designed for through-hole mounting with solder termination for reliable connections. Operates in temperature range from -55°C to 125°C providing wide environmental tolerance. Features male contact gender with multi-finger BeCu contact system for high reliability.

Shrouded body enables blind mating and alignment for installation flexibility. Special features include screw down, weld tab, and solder nail options for rugged applications. Suitable for high cycle applications requiring high reliability in electronics and industrial PCB assemblies.
