JST PH Series Female Crimp Terminal 2A Current, 32-28 AWG Wire Size SPH-004T-P0.5S

Free Delivery in India | Lowest Global Shipping Charges

JST PH Series Female Crimp Terminal 2A Current, 32-28 AWG Wire Size SPH-004T-P0.5S



Category Crimp Terminal Brand JST Condition New

Specifications

Country of Origin	China
Brand	JST
Current	2A
Model	SPH-004T-P0.5S
Gender	Female
Contact Material	Phosphor Bronze
Series	PH
Termination Type	Crimp
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-25°C
For Use With	PH Connectors
Contact Plating	Tin
Minimum Wire Size mm²	0.032mm²
Maximum Wire Size mm²	0.08mm²
Minimum Wire Size AWG	32AWG
Maximum Wire Size AWG	28AWG
Maximum Contact Resistance	20mΩ

Key Features

Compatible with JST PH series connectors for reliable wire-to-board connections.
Constructed from phosphor bronze with tin plating for conductivity and corrosion resistance.
Supports wire gauges from 32 AWG minimum to 28 AWG maximum.
Crimp termination type ensures secure mechanical and electrical connection.
Operates effectively between -25°C and 85°C ensuring stability in varied environments.
Maximum contact resistance of 20 milliohms for minimal signal loss.
Designed as a low profile, thin, and disconnectable contact for high-density applications.
Ideal for industrial and electronic applications requiring compact and reliable connectors.

Product Description

JST SPH-004T-P0.5S female crimp terminal is part of the PH series designed for high-density wire-to-board interconnection applications. It supports a current of 2A and is compatible with PH connectors featuring a 2.00 mm pitch. The contact is made from phosphor bronze with tin plating, providing excellent conductivity and corrosion resistance suitable for electronic components.

Wire size compatibility ranges from a minimum of 32 AWG (0.032 mm²) to a maximum of 28 AWG (0.08 mm²), allowing use with fine and medium gauge wires. The crimp termination ensures robust mechanical retention and electrical contact, making it suitable for demanding industrial environments.

The connector operates reliably in temperature ranges spanning from -25°C to 85°C, making it versatile for various ambient conditions. With a maximum contact resistance of 20 milliohms, signal integrity is maintained efficiently. This component features a fully shrouded design for safety and durability in cable assemblies and PCB applications.

This crimp terminal is especially useful in electronics manufacturing, industrial automation, and telecommunications, where compact, reliable, and easy-to-install connectors are critical.

Compatible with JST PH series connectors for reliable wire-to-board connections. Constructed from phosphor bronze with tin plating for conductivity and corrosion resistance. Supports wire gauges from 32 AWG minimum to 28 AWG maximum.

Crimp termination type ensures secure mechanical and electrical connection. Operates effectively between -25°C and 85°C ensuring stability in varied environments. Maximum contact resistance of 20 milliohms for minimal signal loss.

Designed as a low profile, thin, and disconnectable contact for high-density applications. Ideal for industrial and electronic applications requiring compact and reliable connectors. Explore more JST PH series Crimp Terminals and connectors in the Electronics Components category at EnvMart for comprehensive industrial-grade solutions.
