Hirose DF11 Series Female Crimp Terminal, 26AWG Min Crimp, 22AWG Max, Gold Plating, 2A, Phosphor Copper,

The Hirose DF11-22SCFA(04) is a female crimp terminal designed for DF11 Series connectors, engineered to provide robust connectivity for a wide range of electronics and business equipment. With the ability to support wire sizes from 26AWG up to 22AWG, this terminal is ideal for applications requiring space-efficient and reliable signal transmission.

Constructed from phosphor copper and finished with gold plating, the terminal ensures excellent conductivity and long-term durability, optimizing signal retention and minimizing resistance. The crimp termination method allows for secure attachment to wires, facilitating flexible installation in various PCB connectors and wire housing systems. Its compact double-row, 2mm pitch design allows multiple contacts to fit within a 5mm width, maximizing the density of signal lines in limited board space.

Rated for a maximum current of 2A and featuring a contact resistance up to 30mΩ, it is suitable for applications where stable electrical performance is essential. The terminal operates reliably in environments ranging from -30°C up to 85°C, making it suitable for both industrial and commercial settings including printers, copiers and other business equipment requiring multi-harness wire connections.

The DF11-22SCFA(04) can be used in systems where a wide range of wire sizes is required, and its compatibility with automatic insulation displacement machinery ensures efficient cable manufacturing and reduced manual labor. Gold or tin plating selections are available depending on the application, and this variant specifically utilizes gold plating for superior performance.

Business equipment applications are well supported, thanks to the broad variation of connection solutions in the DF11 Series. Insulation displacement and crimping methods prepare connectors for board-to-cable, in-line, and board-to-board deployments, offering flexibility and streamlined design integration.

Typical use cases include industrial electronics, business machines, laboratory devices, and commercial PCB assemblies needing high-density and reliable wiring. The terminal is manufactured in Japan to high standards, ensuring consistent quality for demanding environments.
