Wurth Elektronik WE-CNSW SMD 0805 Unshielded Wirewound Surface Mount Inductor Ferrite Core 0.13 μH Dual ±25 % 744231091
Specifications
| Country of Origin | Malaysia |
|---|---|
| Brand | Wurth Elektronik |
| Height | 1.2mm |
| Length | 2mm |
| Depth | 1.2mm |
| Packaging | Tape & Reel |
| Series | WE-CNSW SMD |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 0.13μH |
| Standards/Approvals | REACH, IEC 61249-2-21, JEDEC JS709B, RoHS |
| Package/Case | 0805 |
| Maximum DC Current | 370mA |
| Pin Count | 4 |
| Maximum DC Resistance | 300mΩ |
| Inductance Tolerance | ±25 % |
| Termination Style | Surface Mount |
| Inductor Construction | Dual |
| Automotive Standard | AEC-Q200 |
Key Features
- Inductance of 0.13 μH with ±25% tolerance for precise circuit requirements.
- Maximum DC current rating of 370 mA ensures reliable operation.
- Ferrite core construction enhances EMI noise suppression at high frequencies.
- Dual wirewound design improves winding symmetry and signal integrity.
- Compact 0805 SMD footprint suitable for dense PCB layouts.
- Unshielded format for economical integration where shielding is not required.
- Operating temperature range from -40°C to 125°C for industrial environments.
- Automotive standard AEC-Q200 compliance for automotive and harsh environment uses.
Product Description
Wurth Elektronik 744231091 WE-CNSW SMD 0805 Unshielded Wirewound Surface Mount Inductor is engineered for high-performance filtering and common mode noise suppression in modern electronics. With a compact 0805 (2 mm x 1.2 mm x 1.2 mm) surface mount package and ferrite core, this inductor delivers an inductance of 0.13 μH ±25%, ideal for applications demanding precise filtering and high speed signal integrity.
The ferrite core construction provides enhanced EMI noise suppression, making it suitable for USB 2.0, Firewire, LVDS, LAN, and other high speed data lines. The dual wirewound design offers improved winding symmetry, resulting in minimal influence on signals and increased device reliability.
This component features a maximum DC current rating of 370 mA and a DC resistance of 300 mΩ, ensuring low power loss and stable operation in a variety of circuit configurations. With automotive standard AEC-Q200 compliance, it is suited for automotive, industrial, and commercial uses where robustness and longevity are essential.
Inductance value of 0.13 μH with ±25% tolerance. Maximum DC current rating of 370 mA. 4-pin compact 0805 SMD package, suitable for automated production and space-saving designs. Unshielded wirewound construction for cost-effective filtering.
Operating temperature range from -40°C to 125°C for industrial versatility. REACH, IEC 61249-2-21, JEDEC JS709B, and RoHS compliance ensure global regulatory acceptance. Dual inductor construction improves common mode suppression at high frequencies.
Tape & Reel packaging is ideal for high-volume manufacturing. Common applications include signal filtering, noise suppression, and electromagnetic interference mitigation in industrial, laboratory, communication, and automotive electronics.
Explore more Surface Mount Inductors and high-performance passive components from Wurth Elektronik on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 0.13 μH with a tolerance of ±25%.
It has a maximum DC current rating of 370 mA, ensuring reliable operation in various circuit configurations.
The operating temperature range is from -40°C to 125°C, making it suitable for industrial environments.
This inductor has dimensions of 2 mm in length, 1.2 mm in depth, and 1.2 mm in height.
The core material of this model is ferrite, which enhances EMI noise suppression.
It complies with REACH, IEC 61249-2-21, JEDEC JS709B, and RoHS standards.
It is packaged in Tape & Reel format, which is ideal for high-volume manufacturing.
This model features a surface mount termination style, suitable for automated production.
The maximum DC resistance is 300 mΩ, which contributes to low power loss during operation.
It is suitable for applications such as signal filtering, noise suppression, and electromagnetic interference mitigation in various electronic devices.
It features a dual wirewound construction that improves winding symmetry and signal integrity.
