Power Integrations AC/DC Converter 7.7A, 530V, -1.3V, 16-Pin eSIP-16K LCS701LG

Power Integrations LCS701LG AC/DC Converter is engineered for high-efficiency conversion in demanding industrial and electronic environments. This integrated converter utilizes a resonant half-bridge LLC topology, delivering robust and efficient offline conversion with minimal external components. With a compact eSIP-16K package and through-hole mount type, it simplifies design and saves PCB space.

The converter supports a maximum input voltage of 15V and minimum input voltage of 11.4V, while providing a maximum output voltage of 530V and a minimum output voltage of -1.3V. It is capable of supplying up to 7.7A output current, making it suitable for power supply designs up to 400W. Operating frequency reaches up to 1 MHz for nominal steady-state operation up to 500 kHz.

Protection features include programmable brown-in/out thresholds, under-voltage, over-voltage, and over-current protection, as well as short-circuit and over-temperature protection. Programmable soft-start ensures reliable performance and system stability. The high level of integration, including gate drivers and MOSFETs, minimizes PCB area and simplifies assembly.

Designed to perform reliably in harsh environments, the LCS701LG operates within a temperature range from -40°C to 150°C. Application areas include industrial power management, laboratory instrumentation, power supply IC development, and advanced electronics requiring safe and efficient AC/DC power conversion.

Delivers a maximum output current of 7.7A for robust power conversion. Supports input voltages from 11.4V to 15V for versatile integration. Offers a maximum output voltage of 530V suitable for demanding applications. Incorporates LLC Half Bridge topology for high efficiency and reliability.

Features over-current, under-voltage, over-voltage, and over-temperature protection. Designed in a compact eSIP-16K package with through-hole mounting for easy PCB integration. Operates reliably from -40°C to 150°C, covering wide industrial operating ranges.

Ideal for industrial, laboratory, power management IC, and electronic applications.

Typical industrial uses: power supply systems, laboratory equipment, electronic manufacturing, and instrumentation. Explore more AC/DC conversion solutions in the Power Integrations semiconductor family on EnvMart.
