Power Integrations AC/DC Converter, 85V 12-Pin eSOP-12B, Maximum Input Voltage 265V, Output Power 15W, LNK6766V
Specifications
| Country of Origin | India |
|---|---|
| Brand | Power Integrations |
| Height | 8.13mm |
| Length | 10.8mm |
| Model | LNK6766V |
| Width | 1.96mm |
| Output Power | 15W |
| Mount Type | Through Hole, Surface |
| Maximum Duty Cycle | 66% |
| Series | LinkSwitch-HP |
| Topology | Flyback |
| Maximum Operating Temperature | 150°C |
| Package Type | eSOP-12B |
| Minimum Operating Temperature | -40°C |
| Switching Frequency | 32kHz |
| Maximum Input Voltage | 265V |
| Standards/Approvals | RoHS |
| Maximum Output Voltage | 85V |
| Minimum Input Voltage | 50V |
| Pin Count | 12 |
| Supply Current | 1.3mA |
Key Features
- Maximum input voltage of 265V enables wide operating range.
- Output power rating is 15W for reliable device performance.
- Integration of 12-pin eSOP-12B package facilitates surface or through-hole mounting.
- Switching frequency set at 32kHz ensures efficient energy conversion.
- Supports flyback topology for improved power supply design flexibility.
- Operates safely between -40°C and 150°C for industrial environments.
- Supply current is 1.3mA, optimizing power efficiency in applications.
- Compliance with RoHS standards guarantees environmentally safe manufacturing.
Product Description
Power Integrations LNK6766V is a highly efficient AC/DC converter designed for primary side regulated constant voltage/constant current switching solutions suitable for adapters and chargers.
The device supports a maximum input voltage of 265V and an output voltage of 85V, delivering 15 watts of output power in a compact 12-pin eSOP-12B package.
Its flyback topology and multimode PWM/PFM controller with quasi-resonant switch technology maximize efficiency and power density, making it ideal for powering cell phones, cordless phones, PDAs, MP3 players, and networking peripherals.
With a switching frequency of 32kHz and operational temperature range from -40°C to 150°C, this converter ensures robust performance under various environmental conditions. The product features a maximum duty cycle of 66% and a supply current of 1.3mA, enhancing energy efficiency.
Installation is versatile with through-hole or surface mounting options, supported by compact physical dimensions of 10.8mm length, 1.96mm width, and 8.13mm height.
Designed with safety, reliability, and RoHS compliance, this converter meets rigorous semiconductor standards. Applications include industrial, telecommunications, and consumer electronics where efficient power management is critical.
Maximum input voltage of 265V enables wide operating range. Output power rating is 15W for reliable device performance. Integration of 12-pin eSOP-12B package facilitates surface or through-hole mounting. Switching frequency set at 32kHz ensures efficient energy conversion.
Supports flyback topology for improved power supply design flexibility. Operates safely between -40°C and 150°C for industrial environments. Compact dimensions: length 10.8mm, width 1.96mm, height 8.13mm. Supply current is 1.3mA, optimizing power efficiency in applications.
Compliance with RoHS standards guarantees environmentally safe manufacturing. Designed for use in chargers for phones, PDAs, portable audio devices, and networking equipment. Explore a wide range of power management components including AC/DC Converters at EnvMart for your industrial and electronic development needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum input voltage for this converter is 265V, allowing for a wide operating range.
This model has an output power rating of 15W, ensuring reliable device performance.
The dimensions of the converter are 10.8mm in length, 1.96mm in width, and 8.13mm in height.
The switching frequency is set at 32kHz, which contributes to efficient energy conversion.
It supports both through-hole and surface mounting options, providing installation flexibility.
The operational temperature range is from -40°C to 150°C, suitable for industrial environments.
This converter utilizes a flyback topology, which enhances power supply design flexibility.
The supply current is 1.3mA, optimizing power efficiency in applications.
The maximum output voltage is 85V, suitable for various applications.
Yes, this converter is compliant with RoHS standards, ensuring environmentally safe manufacturing.
The maximum duty cycle is 66%, which supports efficient operation under load.
This model is designed for use in chargers for phones, PDAs, portable audio devices, and networking equipment.
