Power Integrations 300 V 10 A Silicon Diode 3-Pin Surface Mount TO-263AB LQA20B300C

Name: Power Integrations 300 V 10 A Silicon Diode 3-Pin Surface Mount TO-263AB LQA20B300C
Brand: Power Integrations
SKU: 291763
Price: 1.85 USD
Availability: InStock



Category Semiconductor Diode Brand Power Integrations Condition New

Specifications

Country of Origin	India
Brand	Power Integrations
Height	4.7mm
Length	10.26mm
Model	LQA20B300C
Width	9.25mm
Mount Type	Surface
Series	LQA20B300C
Package Type	TO-263AB
Standards/Approvals	RoHS
Pin Count	3
Maximum Continuous Forward Current If	10A
Peak Reverse Repetitive Voltage Vrrm	300V
Diode Configuration	2x Common Cathode Pair
Rectifier Type	Silicon
Peak Reverse Current Ir	25μA
Peak Non-Repetitive Forward Surge Current Ifsm	350A
Maximum Forward Voltage Vf	1.9V
Peak Reverse Recovery Time trr	12.6ns

Key Features

Maximum continuous forward current of 10A enhances high current handling.
Peak reverse repetitive voltage of 300V ensures reliable blocking capability.
Fast switching with peak reverse recovery time of 12.6ns improves circuit efficiency.
Maximum forward voltage of 1.9V reduces power loss in applications.
Compact 3-pin TO-263AB package suitable for surface mount assembly.
Peak non-repetitive forward surge current of 350A supports transient robustness.
Configuration includes 2x common cathode pair diodes for versatile usage.
Conforms to RoHS standards ensuring environmental compliance.

Product Description

Power Integrations LQA20B300C is a high-performance silicon Schottky diode designed for surface mount application in TO-263AB 3-pin package. It supports a maximum continuous forward current of 10 A and a peak reverse repetitive voltage of 300 V, making it suitable for demanding power electronics circuits.

This diode shows fast switching characteristics with a peak reverse recovery time of 12.6 ns and a maximum forward voltage of 1.9 V, which optimizes efficiency and reduces switching losses. The diode's peak non-repetitive forward surge current rating of 350 A provides resilience to transient current spikes.

The device features a 2x common cathode pair diode configuration, ideally suited for motor driver circuits, DC-AC converters, and power factor correction (PFC) circuits. Its compact dimensions of 10.26 mm length, 9.25 mm width, and 4.7 mm height ensure space-saving on printed circuit boards.

Manufactured in compliance with RoHS standards, the LQA20B300C diode offers a responsible and environmentally safe choice for power rectification needs in industrial, automotive, and electronic equipment.

Maximum continuous forward current of 10 A provides robust current handling capability. Peak reverse repetitive voltage of 300 V secures protection against reverse voltage. Fast switching with a peak reverse recovery time of 12.6 ns ensures efficient operation.

Package type TO-263AB facilitates surface mount technology assembly. Low forward voltage drop reduces power dissipation in circuits. High peak non-repetitive forward surge current up to 350 A enhances durability. Compact size enables efficient PCB layout and integration.

Compliance with RoHS promotes eco-friendly manufacturing.

Ideal for use in industrial power supplies, motor control circuits, DC-AC power converters, and power factor correction modules. Explore the full Power Integrations range for reliable semiconductor components on EnvMart.
