Nexperia 40 V 500 mA Schottky Diode, SOT-23, Surface Mount, Single, 3-Pin PMEG4005ET,215

Nexperia PMEG4005ET,215 Schottky Diode is engineered for high efficiency in electronic power and connector applications. The diode features a 40 V peak reverse repetitive voltage and a maximum continuous forward current of 500 mA, making it ideal for use in low voltage, high current circuits. The SOT-23 surface-mount package allows for integration into densely populated PCB designs, providing considerable space savings compared to through-hole alternatives.

This Schottky diode is designed to minimize power switching losses thanks to its low forward voltage drop (maximum 470 mV) and low leakage current. The device operates reliably within a temperature range of -65°C to 150°C, ensuring stable performance under various environmental conditions, including industrial and commercial settings.

The single diode configuration and 3-pin SOT-23 form factor enable easy circuit layout and assembly in automated production environments. Peak non-repetitive forward surge current is rated at 10 A for handling brief overloads, while the low capacitance supports high-speed switching and signal rectification. Typical applications for this diode include power management, voltage clamping, rectification, reverse polarity protection, and fast switching circuits in consumer electronics, telecommunications, automotive, and industrial equipment.

The PMEG4005ET,215 is part of the PMEG4005ET series, offering reliability and optimized junction temperature for demanding designs. Its ultra-small, low-profile design ensures compatibility with compact assemblies, while the robust construction and precise electrical parameters guarantee longevity and consistent performance.

This Schottky diode is used in a wide range of applications including industrial automation, power supplies, signal processing, and protection circuits. Its low leakage current and negligible switching losses make it particularly suitable for energy-efficient designs. The SOT-23 package, combined with surface-mount technology, allows for faster production cycles and higher throughput in modern electronics manufacturing.

High efficiency Schottky barrier diode for surface-mount technology. Low forward voltage drop and high junction temperature for improved power efficiency. 3-pin SOT-23 format for compact circuit integration. Operational range from -65°C to 150°C, suitable for varied industrial and commercial uses.

Reliable for fast switching, reverse polarity protection, and voltage rectification. Browse more Schottky Diodes, rectifiers, and industrial electronic components from Nexperia and other leading brands on EnvMart.
