Crydom CW Series Solid State Relay Panel Mount, 50A Load, 280Vrms, IP20, Screw Terminal CWA2450-10
Specifications
| Country of Origin | India |
|---|---|
| Brand | Crydom |
| Height | 33mm |
| Length | 45.7mm |
| Model | CWA2450-10 |
| IP Rating | IP20 |
| Mount Type | Panel |
| Output type | AC |
| Series | CW |
| Maximum Operating Temperature | 80°C |
| Capacitance | 8pF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Screw |
| Switching Function | Instant On |
| Maximum Load Current | 50A |
| Standards/Approvals | TUV Approved, UL/CSA, CE to EN60950-1 |
| Minimum Control Voltage | 90V ac |
| Off State Leakage Current | 1mArms |
Key Features
- Reliable solid state relay for high current switching up to 50A.
- Panel mount design with universal screw terminals for easy installation.
- Supports maximum load voltage up to 280Vrms for wide compatibility.
- Low off-state leakage and instantaneous switching ensure accurate control.
- Fingerproof cover and IP20 rating for enhanced safety during operation.
- LED status indicator provides clear visual feedback of relay status.
- EMC compliant construction ensures robust performance in industrial environments.
Product Description
Crydom CWA2450-10 is a high-performance solid state relay engineered for panel mounting applications. It enables reliable switching of loads up to 50A, supporting a wide voltage range up to 280Vrms. Designed for demanding electrical control tasks, this relay offers an efficient and maintenance-free alternative to mechanical relays, suitable for continuous operation.
The CWA2450-10 features universal screw terminals for straightforward installation and connection. Its IP20 rated body and integrated fingerproof cover enhance operator safety during maintenance and routine operation. Low off-state leakage current ensures precise control, while instantaneous switching capability allows for rapid response times, critical for automated and industrial controls.
An LED status indicator is built in to provide intuitive visual feedback of relay operational state, reducing troubleshooting time and improving system visibility. The relay is EMC compliant, making it ideal for applications where electromagnetic compatibility is essential, such as manufacturing, process control, and laboratory environments.
This solid state relay utilizes SCR technology for robust AC output switching and offers a minimum control voltage of 90V AC, with wide compatibility for control voltages up to 280Vrms. It operates effectively within a temperature range from -40°C to 80°C, making it suitable for diverse industrial settings.
Mechanical dimensions are compact (33mm height, 45.7mm length), enabling flexible integration into panels with limited space. The relay is equipped with instantaneous switching, universal connectors, and an integrated removable fingerproof cover for added safety.
Crydom CW series relays are recognized for their durability and compliance with multiple global standards, including TUV, UL/CSA, and CE to EN60950-1. Typical applications include industrial automation, HVAC systems, motor control, manufacturing machinery, and process control panels.
Explore more high-quality electrical control solutions in EnvMart’s Solid State Relays category or browse Crydom’s full range for advanced panel mounting relays.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model can handle a maximum load current of 50A.
It supports a maximum load voltage of up to 280Vrms.
It features universal screw terminals for easy installation and connection.
The CWA2450-10 has an IP20 rating, providing protection against solid objects greater than 12mm, but not against water.
It operates effectively within a temperature range from -40°C to 80°C.
The relay has a height of 33mm and a length of 45.7mm, making it compact for panel mounting.
It provides an AC output type, utilizing SCR technology for robust switching.
The minimum control voltage for the CWA2450-10 is 90V AC.
Yes, it includes an LED status indicator that provides visual feedback of the relay's operational state.
It features a fingerproof cover and is designed with an IP20 rating for enhanced safety during operation.
It is TUV approved and complies with UL/CSA and CE to EN60950-1 standards.
Typical applications include industrial automation, HVAC systems, motor control, and process control panels.
