Samtec Right Angle Surface PCB Header, Shrouded, 30 Contacts, 2 mm Pitch, 2 Rows, 3.3A, 250V T1M-15-F-SH-L-K
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 3.3A |
| Model | T1M-15-F-SH-L-K |
| Mount Type | Surface |
| Housing Material | Natural LCP |
| Contact Material | Phosphor Bronze |
| Series | T1M |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -10°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Silver, Tin |
| Number of Contacts | 30 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Row Pitch | 1mm |
Key Features
- Features a robust shrouded design for protection and alignment.
- Equipped with 30 phosphor bronze male pins for strong electrical contacts.
- 2 mm pitch and dual row configuration allow space-efficient PCB connectivity.
- Supports surface mount solder termination for automated assembly.
- Rated for 250V maximum voltage and 3.3A current per contact.
- Natural LCP housing provides high-temperature and mechanical stability.
- Contact plating includes silver and tin for reliable conductivity and corrosion resistance.
- Operates reliably within a temperature range from -10°C to 85°C.
Product Description
The Samtec T1M-15-F-SH-L-K is a right angle surface mount PCB header designed for precise wire-to-board connections in electronic circuit assemblies. With a shrouded body and 30 phosphor bronze male contacts arranged in two rows, this header delivers robust performance, secure mating, and excellent alignment for high-density applications.
Engineered with a 2 mm pitch and 1 mm row spacing, the connector is compact and fits space-constrained PCB layouts, reducing signal interference and supporting multi-row configurations. Its shrouded design guards against accidental misalignment or damage during connector insertion or removal.
The contacts are plated with silver and tin, enhancing electrical conductivity and long-term corrosion resistance, making it suitable for demanding industrial environments. The natural LCP housing is built for durability and high-temperature stability, ensuring reliable operation even under elevated soldering and field conditions.
This PCB header is designed for surface mount solder termination, facilitating compatibility with automated assembly processes used in electronic manufacturing. It operates safely within a voltage rating of 250V and supports up to 3.3A per contact, delivering performance necessary for both signal and power transmission modules.
Its right angle orientation is optimal for edge or vertical PCB designs, streamlining the use of space and providing easy access for service or expansion boards. The two-row configuration allows flexible connections in multi-board applications including industrial control, instrumentation, communication equipment, and commercial electronics.
The Samtec T1M-15-F-SH-L-K header is primarily used in industries such as electronics manufacturing, industrial automation, laboratory instruments, control systems, and commercial PCB assembly. Its high reliability, compact footprint and secure mating make it a preferred choice for engineers seeking quality and performance in board-to-board or wire-to-board connectors.
Explore more connectors, headers, and Samtec solutions in the PCB Header category with EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this model is 250V.
This PCB header supports a current capacity of up to 3.3A per contact.
It features a total of 30 contacts arranged in two rows.
The pitch size of this connector is 2 mm.
The housing is made from natural LCP, and the contacts are constructed from phosphor bronze with silver and tin plating.
It uses surface mount solder termination for compatibility with automated assembly processes.
The operating temperature range is from -10°C to 85°C.
This PCB header has a right angle orientation, which is suitable for edge or vertical PCB designs.
The shrouded design provides protection against accidental misalignment and damage during insertion or removal.
It is commonly used in electronics manufacturing, industrial automation, laboratory instruments, and commercial PCB assembly.
The row spacing for this PCB header is 1 mm.
Yes, its compact design and dual row configuration make it suitable for high-density applications.
