Wurth Elektronik PCB Terminal Block 3-Contact 7.62mm Pitch Through Hole 1 Row 24A 750V 691254410003

Name: Wurth Elektronik PCB Terminal Block 3-Contact 7.62mm Pitch Through Hole 1 Row 24A 750V 691254410003
Brand: Wurth Elektronik
SKU: 83228
Price: 4.46 USD
Availability: InStock



Category PCB Terminal Block Brand Wurth Elektronik Condition New

Specifications

Country of Origin	Romania
Voltage	750V ac
Brand	Wurth Elektronik
Colour	Green
Orientation	Horizontal
Current	24A
Length	23.46mm
Depth	18mm
Width	11.2mm
Mount Type	Through Hole
Series	2544
Number of Rows	1
Pitch	7.62mm
Standards/Approvals	cULus, RoHS, VDE
Number of Contacts	3
Minimum Wire Size mm²	0.05mm²
Maximum Wire Size mm²	3.31mm²
Minimum Wire Size AWG	30AWG
Maximum Wire Size AWG	12AWG

Key Features

Three-contact PCB terminal block supports high-current applications up to 24A.
Features a 7.62mm pitch for robust electrical insulation and easier wire insertion.
Through-hole horizontal mount ensures strong board retention and reliable soldering.
Green color and compact size (23.46mm x 11.2mm x 18mm) save PCB real estate.
Rated for operation at 750V AC and compliant with cULus, RoHS, and VDE standards.
Ideal for modular power and signal connections in industrial, automation, and process equipment.

Product Description

The Wurth Elektronik 691254410003 PCB Terminal Block is part of the 2544 Series and is designed for demanding PCB-mounted power and signal connections. This model provides three contact positions, each supporting currents up to 24 amperes at voltages up to 750V AC. Its generous 7.62mm pitch enhances electrical performance by maximizing insulation, reducing crosstalk, and facilitating easier wire insertion, especially in higher current applications.

The through-hole mounting style enables robust solder connections, ensuring mechanical stability even in environments subject to vibration or repeated re-termination. The horizontal orientation further streamlines wiring in panel assemblies, while the block's overall dimensions (length 23.46mm, width 11.2mm, depth 18mm) contribute to efficient use of PCB space in tightly packed boards.

Accommodating a wire size range from 0.05mm² to 3.31mm² (30 AWG to 12 AWG), this terminal block adapts to a variety of conductor sizes for both signal and power distribution circuits. The green housing is standard for PCB terminal blocks and offers clear identification on the board. The device meets international safety and quality standards (cULus, RoHS, VDE), making it suitable worldwide for industrial, instrumentation, and automation control systems.

Typical use cases include control panels, industrial power supply modules, factory automation installations, and modular electronic devices requiring reliable, high-capacity pluggable connections. The integration of a 1-row, 3-position format supports straightforward terminal identification and layout, improving assembly line productivity.

Whether used for new product development or retrofit applications requiring high-reliability wire-to-board terminations, the Wurth Elektronik 691254410003 empowers designers with a proven, easy-to-implement connectivity solution. Wurth Elektronik is recognized for quality interconnect products throughout the electronics industry.
