Panasonic PCB Power Relay 24V DC Coil 16A SPDT ADJ16024
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Panasonic |
| Height | 16mm |
| Length | 29mm |
| Model | ADJ16024 |
| Width | 13mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | ADJ |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 16A |
| Terminal type | Through Hole |
| Typical Applications | Brake circuits, motor control, time switches |
| Contact Resistance | 100mΩ |
| Standards/Approvals | VDE, RoHS, UL |
| Coil Resistance | 2304Ω |
| Coil Voltage | 24V dc |
| Switching AC Voltage | 250V ac |
| Coil Power | 250mW |
Key Features
- Compact dimensions measuring 29mm length, 13mm width, and 16mm height.
- Designed for PCB mounting with through-hole terminal type.
- Low coil power consumption of 250mW for energy efficiency.
- Silver alloy contact material ensures durability and low contact resistance of 100mΩ.
- Operating temperature range from -40°C to 70°C for versatile environments.
- Supports switching AC voltage up to 250V AC and power up to 4000VA.
- Applications include brake circuits, motor control, and time switches in industrial and automation equipment.
- Compliant with VDE, RoHS, and UL standards for safety and quality assurance.
Product Description
Panasonic ADJ16024 is a high-capacity PCB Power Relay featuring a 24V DC coil and SPDT (Single Pole Double Throw) contact configuration. This relay is engineered to deliver reliable switching performance with a current rating of 16A and switching AC voltage capability up to 250V AC. The compact design measures 29mm in length, 13mm in width, and 16mm in height, making it suitable for PCB mounting using through-hole terminals.
With a coil power of just 250mW, this relay offers energy-efficient operation. Contact materials made of silver alloy provide excellent conductivity and ensure a low contact resistance of 100mΩ, contributing to long service life and dependability. The coil resistance is specified at 2304Ω, supporting stable coil operation.
The ADJ16024 relay is rated for operating temperatures ranging from -40°C to 70°C, allowing deployment in varied industrial and commercial environments. Its switching power capacity reaches 4000VA, making it suitable for applications such as brake circuits, motor control systems, and time switches.
Designed in Japan and certified to meet VDE, RoHS, and UL standards, this Panasonic relay upholds stringent quality and safety requirements. Its robust build and versatile electrical specifications make it a preferred choice for automation, household appliance networks, and industrial control devices.
Compact and high-capacity PCB power relay with a 24V DC coil. SPDT contact arrangement enables diverse switching configurations. Low coil power consumption enhances energy efficiency. Silver alloy contacts provide durability and low resistance.
Wide operating temperature range for reliable functionality in varied conditions. Compliance with international safety and environmental standards. Ideal for use in factory automation equipment, electric power devices, and time switches.
Explore more Panasonic Power Relays and related components at EnvMart to support your electronic design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay measures 29mm in length, 13mm in width, and 16mm in height.
The coil voltage for the Panasonic ADJ16024 is 24V DC.
This model can handle a maximum switching current of 16A.
The contact configuration of this relay is SPDT (Single Pole Double Throw).
The operating temperature range for the Panasonic ADJ16024 is from -40°C to 70°C.
This relay uses a through-hole terminal type for PCB mounting.
The contact material for the Panasonic ADJ16024 is silver alloy, which ensures low contact resistance.
The coil power consumption of the ADJ16024 relay is 250mW, promoting energy efficiency.
This model can switch AC voltage up to 250V AC.
Typical applications include brake circuits, motor control, and time switches in industrial and automation equipment.
The relay is compliant with VDE, RoHS, and UL standards for safety and quality assurance.
The contact resistance of the Panasonic ADJ16024 is specified at 100mΩ.
