TDK SIMID 2220 Unshielded Wirewound Surface Mount Inductor with Ferrite Core 4.7 μH ±10 % 1.95 A DC Current B82442T1472K000
Specifications
| Country of Origin | Hungary |
|---|---|
| Brand | TDK |
| Height | 5mm |
| Length | 5.6mm |
| Model | B82442T1472K000 |
| Depth | 5mm |
| Packaging | Tape & Reel |
| Series | SIMID |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Ferrite |
| Inductance | 4.7μH |
| Standards/Approvals | JEDEC J-STD 020D, RoHS, AEC-Q200 |
| Package/Case | 2220 |
| Maximum DC Current | 1.95A |
| Maximum DC Resistance | 73mΩ |
| Inductance Tolerance | ±10 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 30MHz |
| Minimum Quality Factor | 15 |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Features a ferrite core for efficient performance.
- Packaged in tape and reel with a 2220 case size.
- Operates reliably between -55°C and 150°C temperatures.
- Complies with JEDEC J-STD 020D, RoHS, and AEC-Q200 standards.
- Maximum DC resistance is 73 mΩ for minimal power loss.
- Constructed with wirewound design and laser-welded winding.
- Suitable for automotive and industrial applications.
- Has a high quality factor of 15 and maximum self-resonant frequency of 30 MHz.
Product Description
The TDK B82442T1472K000 SIMID series is an unshielded wirewound surface mount inductor with a ferrite drum core. It provides a stable inductance value of 4.7 μH with a tolerance of ±10 %, designed for high-reliability applications with a maximum DC current rating of 1.95 A. The device is manufactured with laser-welded winding and flame-retardant molding to ensure durability and performance under harsh operating conditions.
This inductor is compact with a 2220 package size measuring 5.6 mm length, 5 mm height, and 5 mm depth, making it suitable for dense PCB layouts. Packaged on tape and reel, it facilitates automated assembly processes.
The component meets industry standards including JEDEC J-STD 020D, RoHS compliance, and the automotive standard AEC-Q200, making it ideal for automotive electronics, telecommunications, consumer electronics, and various industrial equipment. It supports a wide temperature range from -55°C to +150°C and offers a maximum DC resistance of 73 mΩ to minimize losses.
Its wirewound construction with a ferrite core provides high quality factors, with a minimum Q of 15 and a maximum self resonant frequency of 30 MHz, maximizing efficiency in filtering power supplies, DC-DC converters, and switch-mode power supply circuits.
This inductor is suitable for lead-free reflow soldering, halogen-free, and certified for reliable use in critical electronic applications. Features a ferrite core for efficient performance. Packaged in tape and reel with a 2220 case size.
Operates reliably between -55°C and 150°C temperatures. Complies with JEDEC J-STD 020D, RoHS, and AEC-Q200 standards. Maximum DC resistance is 73 mΩ for minimal power loss. Constructed with wirewound design and laser-welded winding.
Suitable for automotive and industrial applications. Has a high quality factor of 15 and maximum self-resonant frequency of 30 MHz. Explore more Surface Mount Inductors and related components on EnvMart to find the ideal part for your electronics projects and industrial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 4.7 μH with a tolerance of ±10%.
This inductor has a maximum DC current rating of 1.95 A.
The dimensions of this unit are 5.6 mm in length, 5 mm in height, and 5 mm in depth, packaged in a 2220 case size.
It operates reliably between -55°C and +150°C.
It complies with JEDEC J-STD 020D, RoHS, and AEC-Q200 standards.
The maximum DC resistance is 73 mΩ, which helps minimize power loss.
The maximum self-resonant frequency is 30 MHz.
It is packaged on tape and reel, facilitating automated assembly processes.
This inductor features a wirewound construction with a ferrite core.
The minimum quality factor is 15, indicating efficient performance.
It is suitable for automotive electronics, telecommunications, consumer electronics, and various industrial equipment.
The termination style for this model is solder.
