Nexperia Schottky Diode 40 V 200 mA Surface Mount 3-Pin SC-70 BAT854CW

Nexperia BAT854CW Schottky Diode is a high-efficiency, ultra-small, low-profile surface mount diode designed for electronic applications requiring low forward voltage drop and high junction temperature tolerance. The device’s 3-pin SC-70 package offers space-saving advantages in compact circuits.

Featuring a maximum continuous forward current of 200 mA and a peak reverse repetitive voltage of 40 V, this Schottky diode is suitable for general-purpose protection and rectification tasks in semiconductor circuits.

Its common cathode diode configuration and low forward voltage of 550 mV minimize power consumption and heat generation, beneficial in low-voltage DC to DC converters, power supply circuits, and signal detection.

The component operates over an extended temperature range from -65°C to 150°C, ensuring reliable function in harsh environments including automotive electronics, industrial, and commercial electronic devices. Compliance with the AEC-Q101 automotive standard underscores its robustness for vehicular applications.

The package dimensions are 2.2 mm in length, 1.35 mm in width, and 1 mm in height, allowing easy PCB integration with minimal footprint. The diode supports a peak non-repetitive forward surge current of 1 A, enhancing its durability against transient current spikes.

Maximum continuous forward current of 200 mA ensures stable operation. Peak reverse repetitive voltage rating of 40 V provides circuit protection. Low forward voltage drop reduces power dissipation. Small 3-pin SC-70 surface mount package optimizes PCB space.

Wide operating temperature from -65°C to 150°C supports diverse applications. Extremely low reverse leakage current with 500 nA peak reverse current. Meets automotive standard AEC-Q101 for reliability in critical systems.

Supports surge current up to 1 A for transient protection. Produced in Malaysia adhering to strict quality standards.

This Nexperia Schottky Diode is ideal for use in industrial electronics, automotive power supplies, telecommunication devices, and consumer electronics, enhancing efficiency and reliability. Its low voltage drop and small size make it suitable for applications requiring fast switching and low power loss.
