onsemi 1.1GHz Oscillator, 8-Pin SOIC Package, ECL Output Level, Operating -40°C to 85°C MC100EL1648DG
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.5mm |
| Length | 5mm |
| Model | MC100EL1648DG |
| Width | 4mm |
| Series | MC100EL1648 |
| Maximum Operating Temperature | 85°C |
| Output Frequency | 1.1GHz |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | UL 94 V-0, JEDEC Standard EIA, JESD78 |
| Pin Count | 8 |
| Output Level | ECL |
Key Features
- Operates at an output frequency of 1.1GHz suitable for high-frequency circuits.
- Encased in compact 8-Pin SOIC package measuring 5mm by 4mm by 1.5mm.
- Designed to function reliably between -40°C and 85°C operating temperature range.
- Compliance with UL 94 V-0, JEDEC Standard EIA, and JESD78 standards ensures quality and safety.
- Not intended for automotive applications indicated by automotive standard 'No'.
- Oscillator utilizes ECL output level for fast switching performance.
- Typically used in voltage controlled oscillator (VCO) and phase-locked loop (PLL) applications.
- Robust build suitable for industrial, manufacturing, and electronic test environments.
Product Description
onsemi MC100EL1648DG is a high-performance 1.1GHz oscillator featuring an 8-Pin SOIC package designed for precision electronic applications.
This oscillator delivers a stable ECL output level and is engineered to operate within a temperature range from -40 degrees Celsius to 85 degrees Celsius, supporting demanding environments.
Compact dimensions of 5mm length, 4mm width, and 1.5mm height allow for efficient circuit board placement, making it ideal for modern electronic devices and industrial control systems.
It complies with safety and quality certifications including UL 94 V-0 flammability rating, JEDEC Standard EIA, and JESD78, ensuring reliability and conformance with industry standards.
This product is not certified for automotive use but is well suited for industrial electronics, laboratory equipment, telecommunications, and manufacturing process controls where precise oscillation frequency is critical.
Operates at 1.1GHz frequency with ECL output level for high-speed digital signals. Compact 8-Pin SOIC housing measuring 5mm x 4mm x 1.5mm for easy PCB integration. Wide operating temperature from -40°C to 85°C supports harsh environments.
Meets UL 94 V-0 flammability and JEDEC standards EIA, JESD78. Voltage controlled oscillator (VCO) and PLL-compatible for frequency synthesis applications. Ideal for use in industrial, manufacturing, laboratory, telecommunications, and embedded systems.
Not suitable for automotive standard compliance. Explore more Oscillators and frequency control solutions at EnvMart for advanced electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates at an output frequency of 1.1GHz, suitable for high-frequency circuits.
This model functions reliably within a temperature range of -40°C to 85°C.
The package measures 5mm in length, 4mm in width, and 1.5mm in height.
It utilizes an ECL output level, which is designed for fast switching performance.
Yes, it complies with UL 94 V-0, JEDEC Standard EIA, and JESD78 standards, ensuring quality and safety.
It is commonly used in voltage controlled oscillator (VCO) and phase-locked loop (PLL) applications.
This model features an 8-pin configuration.
No, it is not intended for automotive applications as indicated by the automotive standard 'No'.
It is well suited for industrial electronics, laboratory equipment, telecommunications, and manufacturing process controls.
This oscillator belongs to the MC100EL1648 series.
The country of origin for this product is India.
The maximum operating temperature is 85°C.
