DiodesZetex 4 2-Input AND Schmitt Trigger Input Logic Gate, 14-Pin SOIC 74HC08S14-13

DiodesZetex 74HC08S14-13 is a 4 2-Input AND Schmitt Trigger Input Logic Gate housed in a 14-Pin SOIC package. This device belongs to the 74HC logic family providing high-speed CMOS logic functions with low power consumption, ideal for electronic and semiconductor applications requiring stable and noise-immune logic gating.

The logic gate integrates four independent 2-input AND gates featuring Schmitt trigger inputs to enhance the noise immunity of the circuit by providing hysteresis. The gate operates over a supply voltage range of 2 V to 6 V, making it adaptable to a variety of voltage environments.

Its maximum propagation delay of 23ns and push-pull output configuration make this device suitable for fast-switching digital logic circuits in industrial, laboratory, and electronics manufacturing settings. It supports continuous operation in temperature extremes from -40°C to 125°C, making it reliable for harsh environments.

The compact 14-pin SOIC surface-mount package with precise dimensions (1.48mm height and 8.74mm length) ensures efficient PCB mounting and integration.

Additional robustness is provided by compliance with ESD standards, safeguarding against damage in handling and operation. The device is made to exacting standards in China, ensuring quality and consistency.

This logic gate device integrates four 2-input AND gates with Schmitt trigger inputs for enhanced noise immunity. The product features a 14-pin SOIC package suitable for surface mounting. It operates over a wide supply voltage range of 2 V to 6 V for flexible power configurations.

Maximum propagation delay is 23ns, supporting fast switching for digital circuits. The device operates reliably between -40°C and 125°C temperature range for industrial applications. It has push-pull output type and supports a maximum high level output current of -4mA.

Manufactured in China with precise dimensions of 8.74mm length and 1.48mm height.

This Logic Gate is widely applicable in electronic component, industrial automation, and semiconductor product development sectors. It is compatible with CMOS-based logic families and suited for building reliable, noise-resistant logic circuits within manufacturing and testing equipment.
