TDK Shielded Wirewound Surface Mount Inductor with Ferrite Core 220μH ±20/±30% 1.2A Idc SLF12565T-221M1R0-PF
Specifications
| Country of Origin | India |
|---|---|
| Brand | TDK |
| Height | 6.5mm |
| Length | 12.5mm |
| Model | SLF12565T-221M1R0-PF |
| Depth | 7.5mm |
| Packaging | Taping |
| Series | SLF |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 220μH |
| Standards/Approvals | RoHS |
| Package/Case | 12565 |
| Maximum DC Current | 1.2A |
| Maximum DC Resistance | 273mΩ |
| Inductance Tolerance | ±20/±30 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
Key Features
- The inductor has a compact 12565 package/case designed for surface mounting.
- It offers a maximum operating temperature of 105°C, suitable for various electronic applications.
- Constructed with a ferrite core and wirewound design ensuring effective EMC reduction.
- The device includes shielding to minimize electromagnetic interference in circuits.
- It features a low DC resistance of 273mΩ, optimizing efficiency.
- The inductance tolerance is specified as ±20% and ±30%, allowing tolerance versatility.
- Termination style is surface mount type, compatible with modern SMT assembly.
- The inductor has a length of 12.5mm, height of 6.5mm, and depth of 7.5mm.
Product Description
TDK SLF12565T-221M1R0-PF is a shielded wirewound surface mount inductor featuring a ferrite core and designed to deliver an inductance of 220μH with tolerance levels of ±20% and ±30%. It supports a maximum DC current of 1.2 A, making it well-suited for various electronic and industrial applications.
This inductor is encapsulated within a compact 12565 package case, with dimensions of 12.5mm length, 6.5mm height, and 7.5mm depth. The ferrite core and wirewound construction provide stability and effective power line inductance, while the magnetic shielding helps reduce electromagnetic interference (EMI) in sensitive circuits.
It is rated for operation in a temperature range from -40°C to 105°C, ensuring reliable performance in harsh and varying environmental conditions. The component’s maximum DC resistance of 273mΩ contributes to minimal power loss and high efficiency.
Surface mount termination style facilitates modern rapid PCB assembly, and the product is packaged in tape for compatibility with automated manufacturing processes. It is RoHS compliant, meeting industry regulations for environmental standards.
Typical applications include portable telephones, personal computers, hard disk drives, and other consumer and industrial electronic equipment where EMI suppression is critical. The inductor’s magnetic shielding and wirewound design make it effective for EMC reduction in electronic circuits.
The ferrite core provides high inductance in a small footprint. Compact SMT package supports space-saving PCB designs. Wide operating temperature range supports use in challenging environments. Low DC resistance enhances overall circuit efficiency.
Tape packaging enables streamlined manufacturing integration. Compliance to RoHS directives ensures eco-friendly usage. Ideal for high current applications up to 1.2 A. Surface mount termination style fits standard SMT processes.
Reliable performance backed by TDK’s quality standards.
Explore more high-quality Surface Mount Inductors like the TDK SLF12565T-221M1R0-PF in EnvMart’s comprehensive Electronics & Electricals catalog for your industrial and commercial requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features an inductance value of 220μH with tolerance levels of ±20% and ±30%.
It supports a maximum DC current of 1.2A, making it suitable for high current applications.
The dimensions are 12.5mm in length, 6.5mm in height, and 7.5mm in depth.
The maximum operating temperature is 105°C, allowing it to function in various electronic applications.
It is constructed with a ferrite core, which aids in effective electromagnetic interference reduction.
The inductor is packaged in tape, facilitating compatibility with automated manufacturing processes.
It features a surface mount termination style, suitable for modern SMT assembly.
The maximum DC resistance is 273mΩ, contributing to its efficiency in circuit applications.
The country of origin for this model is India.
It operates within a temperature range of -40°C to 105°C, suitable for challenging environments.
This inductor is RoHS compliant, meeting industry regulations for environmental standards.
Typical applications include portable telephones, personal computers, and hard disk drives, where EMI suppression is critical.
