onsemi 4 2-Input NAND Schmitt Trigger Input Logic Gate, Surface Mount SOIC 14-Pin MC14093BDR2G

onsemi MC14093BDR2G is a 4 2-Input NAND Schmitt Trigger Input Logic Gate enclosed in a 14-pin Surface Mount SOIC package. It belongs to the 4000 CMOS logic family and is designed to operate within a wide supply voltage range from 3V to 18V, making it versatile for various electronic circuit designs.

The device integrates four NAND gates with 2 Schmitt trigger inputs each, providing enhanced noise immunity and signal conditioning. With a maximum propagation delay time of 80 nanoseconds at typical capacitive loads, it supports moderate switching speeds suited for many industrial and automotive digital logic functions.

Operating temperature ranges from -55°C to 125°C ensure reliability under harsh environmental conditions, complying with automotive industry standard AEC-Q100. The device outputs can provide maximum high and low-level currents of ±4.2mA suitable for driving modest loads in logic circuits.

The compact 14-pin SOIC surface mount package measures approximately 8.75mm in length and 1.5mm in height, enabling space-saving PCB designs. This logic IC is widely used in electronic components, power control systems, embedded system designs, and automotive electronics.

This Logic Gate features four NAND gates with 2 inputs each. Each gate uses Schmitt trigger inputs for improved noise immunity. Operates over a wide voltage range of 3V to 18V. Maximum propagation delay time is 80ns at capacitive load.

Designed for operating temperatures from -55°C up to 125°C. Complies with automotive standard AEC-Q100 for reliability. Provides maximum high and low-level output currents of ±4.2mA. Compact 14-pin SOIC package measures 8.75mm length and 1.5mm height.

Ideal for industrial, automotive, and general purpose logic applications.

This product is suitable for application in industrial automation systems, electronic manufacturing, automotive circuitry, and general logic control tasks. Its robust operating parameters and surface mount package type contribute to enhanced design flexibility and reliability.
