Nexperia Resistor-Equipped Transistor NPN 100 mA 50 V 3-Pin DFN1412D-3 PDTC143XQC-QZ

Free Delivery in India | Lowest Global Shipping Charges

Nexperia Resistor-Equipped Transistor NPN 100 mA 50 V 3-Pin DFN1412D-3 PDTC143XQC-QZ

Name: Nexperia Resistor-Equipped Transistor NPN 100 mA 50 V 3-Pin DFN1412D-3 PDTC143XQC-QZ
Brand: Nexperia
SKU: 406015
Price: 0.21 USD
Availability: InStock



Category Bipolar Transistors Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Model	PDTC143XQC-QZ
Mount Type	Surface
Series	PDTC143X
Maximum Operating Temperature	150°C
Package Type	DFN1412D-3
Minimum Operating Temperature	-55°C
Standards/Approvals	RoHS
Pin Count	3
Maximum Collector Emitter Voltage Vceo	50V
Minimum DC Current Gain hFE	50
Transistor Polarity	NPN
Maximum Emitter Base Voltage VEBO	7V
Maximum Collector Base Voltage VCBO	50V
Automotive Standard	AEC-Q101
Maximum DC Collector Current Idc	100mA
Transistor Configuration	NPN
Maximum Transition Frequency ft	230MHz

Key Features

Equipped with built-in resistors to simplify circuit designs.
Compact 3-pin DFN1412D-3 plastic package with side-wettable flanks.
Supports a maximum collector current of 100 mA and collector-emitter voltage of 50 V.
Minimum DC current gain (hFE) of 50 for reliable performance.
Wide operating temperature range from -55°C to 150°C.
Low package height of 0.5 mm suitable for surface mounting.
Certified RoHS compliant and meets AEC-Q101 automotive standard.
Ideal as cost-saving alternative to BC857 series in controlling IC inputs and switching loads.

Product Description

Nexperia PDTC143XQC-QZ is a resistor-equipped NPN bipolar transistor in a compact 3-pin DFN1412D-3 surface mount package. It features built-in resistors that reduce external component count and simplify circuit design, making it well suited for digital and switching applications in industrial electronics and automotive systems.

This transistor supports a maximum DC collector current of 100 mA and maximum collector-emitter voltage of 50 V. It operates reliably over a wide temperature range of -55°C to +150°C and has a minimum DC current gain (hFE) of 50. The ultra thin plastic package has side-wettable flanks and a low profile of 0.5 mm, facilitating assembly on automated production lines and enabling optical inspection methods.

The PDTC143XQC-QZ transistor is RoHS compliant and meets the rigorous AEC-Q101 automotive qualification standard, ensuring durability and safety in automotive electronic circuits. It is an excellent cost-effective replacement for the BC857 series in circuits requiring NPN transistors with integrated resistors.

Built-in resistors reduce component count and simplify circuit design. Ultra-small DFN1412D-3 (SOT8009) surface mount package. Maximum collector current: 100 mA, voltage rating: 50 V. Minimum DC current gain (hFE): 50 for stable amplification.

Wide operating temperature range from -55°C to 150°C. Low profile package height of 0.5 mm suitable for automatic assembly. RoHS compliant and AEC-Q101 automotive qualified. Ideal for digital applications, switching loads, and controlling IC inputs.

Compatible with pick and place manufacturing and automatic optical inspection (AOI).

This device is widely used in industrial controls, automotive electronics, consumer devices, and telecommunications equipment where compact, reliable transistors with integrated resistors are required. Engineers benefit from reduced PCB real-estate and lower component counts when using PDTC143XQC-QZ transistors.
