Samtec SSQ Series Straight Through Hole PCB Socket 40-Contact 2 Row 2.54 mm Pitch SSQ-120-04-T-D

Free Delivery in India | Lowest Global Shipping Charges

Samtec SSQ Series Straight Through Hole PCB Socket 40-Contact 2 Row 2.54 mm Pitch SSQ-120-04-T-D

Name: Samtec SSQ Series Straight Through Hole PCB Socket 40-Contact 2 Row 2.54 mm Pitch SSQ-120-04-T-D
Brand: Samtec
SKU: 402296
Price: 5.58 USD
Availability: InStock



Category PCB Sockets Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	655V
Brand	Samtec
Orientation	Straight
Current	6.3A
Model	SSQ-120-04-T-D
Mount Type	Through Hole
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	SSQ
Termination Type	Through Hole
Maximum Operating Temperature	105°C
Sub Type	Socket Strip
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Tin
Number of Contacts	40
Contact Gender	Female
Connector System	Board-to-Board
Row Pitch	2.5mm

Key Features

Constructed with a black liquid crystal polymer housing for high durability.
Features phosphor bronze contacts with matte tin plating for reliable conductivity.
Rated for a current of 6.3 A and voltage up to 655 V.
Designed for through-hole mounting with a standard 2.5 mm row pitch.
Operates effectively between -55°C to 105°C temperature range.
Connector system supports board-to-board interfacing with female contact gender.
Standard and low insertion force contact with 0.635 mm square tail for self-nesting application.

Product Description

Samtec SSQ-120-04-T-D is a high-quality PCB socket designed for straight through hole mounting, featuring 40 contacts arranged in 2 rows with a 2.54 mm pitch. The socket is part of the SSQ series and uses a durable black liquid crystal polymer housing. This component ensures reliable board-to-board connectivity in industrial and electronic applications.

The contacts are made of phosphor bronze, plated with matte tin to provide excellent electrical conductance and corrosion resistance. Rated for a current of 6.3 A and voltage up to 655 V, this socket supports demanding power and signal transmission requirements.

Its through-hole termination type and 2.5 mm row pitch makes it compatible with standard PCB layouts. The contact design includes standard and low insertion force features with a 0.635 mm square tail, enabling a secure and easy assembly process.

Operating temperature ranges from -55°C to 105°C, making it suitable for various industrial, manufacturing, electronics assembly, and automation control environments. The female contact gender and board-to-board connector system facilitate versatile connectivity options in complex electronic devices.

Black liquid crystal polymer housing ensures mechanical strength and thermal stability. Phosphor bronze contacts plated with matte tin provide reliable electrical pathways. Supports 6.3 A current and 655 V voltage ratings suitable for industrial uses.

Through-hole mounting with a 2.5 mm row pitch for PCB compatibility. Wide operating temperature ensures performance stability from -55°C to 105°C. Standard and low insertion force contact design for ease of use. Board-to-board female contact configuration for secure interconnections.

This Samtec SSQ PCB socket is ideal for industrial electronics, test and measurement equipment, communication devices, and power supply boards. It offers durability, performance, and ease of integration required in rigorous environments.
