Samtec SSW Series Straight Through Hole PCB Socket 5-Contact 1 Row 2.54 mm Pitch Surface Mount SSW-105-22-G-S-VS
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 655V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4.7A |
| Model | SSW-105-22-G-S-VS |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Current Rating | 4.7A per pin(2 pins powered) |
| Series | SSW |
| Termination Type | Surface Mount |
| Maximum Operating Temperature | 125°C |
| Sub Type | Solder Tail |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Max Cycles | 100 with 10μ" (0.25μm) Au |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 5 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
| Insulator Material | black LCP |
Key Features
- Constructed with phosphor bronze contact material for reliable conductivity.
- Features a black liquid crystal polymer housing providing durable insulation.
- Supports a current rating of 4.7 A per pin (2 pins powered) ensuring robust power handling.
- Designed with a straight orientation and through hole mount type for board-to-board connections.
- Contact plating is gold to ensure corrosion resistance and longevity.
- Operates within a temperature range of -55°C to 125°C suitable for harsh environments.
- Max cycle life of 100 with 10μ" (0.25μm) gold plating maintaining performance over repeated use.
Product Description
Samtec SSW-105-22-G-S-VS is a high-quality straight through hole PCB socket from the SSW series, designed for reliable board-to-board electrical connections. This PCB socket offers 5 contacts arranged in a single row with a standard 2.54 mm pitch and surface mount solder tail termination. The socket's black housing is made of liquid crystal polymer which offers excellent mechanical durability and electrical insulation for demanding industrial and electronic applications.
Featuring phosphor bronze contact material and gold plating, the socket ensures excellent electrical performance, corrosion resistance, and a robust contact interface. It supports a continuous current rating of 4.7 A per pin with 2 pins powered, making it suitable for medium power PCB interconnect use cases. The voltage rating of 655 V AC/DC allows flexible application across various industrial and commercial electronic equipment.
Its through hole mount type with a straight orientation facilitates easy PCB assembly and firm mechanical stability. With operating temperatures ranging from -55°C to +125°C, this socket is engineered to perform reliably in harsh environmental conditions including industrial automation, power electronics, and telecommunications equipment.
Constructed with phosphor bronze contact material for reliable conductivity. Features a black liquid crystal polymer housing providing durable insulation. Supports a current rating of 4.7 A per pin (2 pins powered) ensuring robust power handling.
Designed with a straight orientation and through hole mount type for board-to-board connections. Contact plating is gold to ensure corrosion resistance and longevity. Operates within a temperature range of -55°C to 125°C suitable for harsh environments.
Voltage rating up to 655 V for AC/DC applications. Max cycle life of 100 with 10μ" (0.25μm) gold plating maintaining performance over repeated use.
This PCB socket is widely used in electronic manufacturing, industrial control systems, power connectors assemblies, and telecommunications hardware. The Samtec SSW series is recognized for its consistent quality and long operational life. Ideal for engineers and technicians requiring reliable connector solutions in demanding applications.
Browse more high-quality PCB Sockets and electronic components at EnvMart for your next project or industrial requirement.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of 4.7 A per pin with 2 pins powered.
The voltage rating is up to 655 V for both AC and DC applications.
The housing is made of black liquid crystal polymer, and the contact material is phosphor bronze with gold plating.
It operates within a temperature range of -55°C to +125°C, making it suitable for harsh environments.
This socket features 5 contacts arranged in a single row.
It is designed for through hole mounting with a straight orientation.
The maximum cycle life is 100 cycles with 10μ" (0.25μm) gold plating.
The pitch size is 2.54 mm.
It features surface mount solder tail termination.
It is widely used in electronic manufacturing, industrial control systems, power connector assemblies, and telecommunications hardware.
The contact gender is female.
The country of origin for this socket is India.
