Samtec BCS Series Straight Through Hole PCB Socket, 3-Contact, 1 Row, 2.54 mm Pitch, 4.6A Current, 475V BCS-103-L-S-TE
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 475V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4.6A |
| Model | BCS-103-L-S-TE |
| Mount Type | Through Hole |
| Special Features | Top and bottom entry pass-through options |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Bronze |
| Series | BCS |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Pass-Through Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | EU RoHS, EU REACH, CHINA RoHS |
| Contact Plating | Gold |
| Number of Contacts | 3 |
| Connector System | Board-to-Board |
| Contact System | Tiger Claw™ |
| Row Pitch | 0.1in |
Key Features
- Constructed from liquid crystal polymer housing material for enhanced durability.
- Supports a current rating of 4.6 amperes and voltage up to 475 volts.
- Features gold-plated bronze contacts with Tiger Claw™ contact system for reliable electrical performance.
- Operates efficiently within a temperature range of -55°C to 125°C.
- Intended for through-hole mounting with a straight orientation suitable for pass-through socket strips.
- Includes top and bottom entry pass-through options for flexible application.
- Complies with EU RoHS, EU REACH, and China RoHS environmental standards.
- Ideal for single and double row configurations up to 100 pins on PCB assemblies.
Product Description
Samtec BCS-103-L-S-TE Straight Through Hole PCB Socket is a high-quality, 3-contact, 1-row pass-through socket strip. It features a 2.54 mm (.100 inch) pitch and is designed for board-to-board connector applications requiring solder termination and through-hole mounting.
This connector is constructed with a robust liquid crystal polymer housing, providing mechanical stability and high-temperature performance. Its bronze contacts are gold-plated to ensure excellent conductivity and corrosion resistance. The patented Tiger Claw™ contact system enhances contact reliability and durability.
Operating within a wide temperature range from -55°C to 125°C, this socket supports electrical currents up to 4.6 amperes and voltage ratings of 475 volts, making it suitable for a wide variety of industrial and electronic applications.
The design includes straight orientation with top and bottom entry pass-through options, accommodating flexible PCB layouts and configurations. This connector is RoHS and REACH compliant, confirming adherence to international environmental and safety standards.
Typical applications include use in industrial electronics, laboratory instrumentation, power connectors, telecommunications, and automation equipment where reliable board-to-board connections are essential.
Supports a 2.54 mm pitch with 3 contacts and 1 row configuration. Liquid crystal polymer housing for enhanced durability and heat resistance. Gold-plated bronze contacts with Tiger Claw™ system for superior connectivity.
Through-hole solder termination ensuring secure PCB mounting. Wide operating temperature range: -55°C to 125°C. Current rating of 4.6A and voltage rating of 475V for robust performance. Complies with EU RoHS, EU REACH, and China RoHS regulations.
Pass-through socket strip suitable for up to 100 pins in single or double row configurations.
This Samtec BCS series PCB socket is a reliable choice for power connectors in electronics manufacturing, industrial control systems, and various commercial applications. Explore EnvMart's range of connection solutions for more options to suit your assembly needs.
Explore more products in our PCB Sockets category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 4.6 amperes.
It has a voltage rating of 475 volts.
The pitch size is 2.54 mm (0.1 inches).
The housing is made from liquid crystal polymer, and the contacts are made of bronze with gold plating.
It operates efficiently within a temperature range of -55°C to 125°C.
This unit is designed for through-hole mounting with solder termination.
Yes, it includes top and bottom entry pass-through options for flexible applications.
It complies with EU RoHS, EU REACH, and China RoHS environmental standards.
This model features 3 contacts in a single row configuration.
It utilizes a board-to-board connector system with a Tiger Claw™ contact system for enhanced reliability.
The country of origin for this PCB socket is India.
Typical applications include industrial electronics, laboratory instrumentation, power connectors, and telecommunications.
