Nexperia 60 V 1.41 A Surface Mount Low Forward Voltage Schottky Diode SOD-123W PMEG6010ELRX

Nexperia PMEG6010ELRX is a low forward voltage Schottky diode packaged in a SOD-123W surface-mount device optimized for medium power applications up to 1.41 A continuous forward current and 60 V peak reverse voltage. It is constructed using planar Maximum Efficiency General Application (MEGA) technology with an integrated guard ring for enhanced stress protection.

This diode is designed for use in electronic circuits requiring efficient rectification with minimal forward voltage drop, which helps extend battery life. Its extremely low leakage current and high power handling capability make it suitable for industrial, automotive, and consumer electronics applications.

The device features a fast peak reverse recovery time of 4.5 ns, enabling it to operate efficiently in high-frequency switching circuits. The compact SOD-123W package supports miniaturized PCB layouts while ensuring robustness with clip-bonding technology.

Operating temperature ranges from -55°C to 175°C permit use in harsh environments. The diode is qualified to the automotive AEC-Q101 standard, assuring compliance with demanding automotive industry reliability requirements.

The diode uses a low forward voltage Schottky barrier technology. Encapsulated in a compact SOD-123W small, flat lead plastic surface-mounted package. Features a maximum continuous forward current of 1.41 A with a peak reverse voltage of 60 V.

Operates reliably across a wide temperature range from -55°C to 175°C. Provides fast recovery with a peak reverse recovery time of 4.5 ns. Low leakage current and high power capability due to clip-bonding technology. Qualified to the automotive standard AEC-Q101 for high reliability in automotive applications.

Ideal for battery life extension and general purpose rectifier applications in industrial, electronic and automotive systems. Compact dimensions of 2.8 mm length, 1.9 mm width and 1.1 mm height enable space-saving PCB designs.

This diode is widely used in power management, power supplies, automotive electronic control modules, and various switching converter circuits. Its efficient rectification characteristics ensure enhanced system performance and longer operational lifetimes.
