ROHM 200 V 1 A Super Fast Recovery Diode Surface Mount SOD-123 Package RF081MM2STR
Specifications
| Country of Origin | India |
|---|---|
| Brand | ROHM |
| Height | 0.8mm |
| Length | 2.6mm |
| Model | RF081MM2STR |
| Width | 1.6mm |
| Mount Type | Surface |
| Series | RF081mm²S |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-123 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 200V |
| Diode Configuration | Single |
| Rectifier Type | Fast Recovery |
| Peak Reverse Current Ir | 10mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 20A |
| Maximum Forward Voltage Vf | 980mV |
| Peak Reverse Recovery Time trr | 25ns |
Key Features
- Maximum continuous forward current of 1 ampere ensures reliable operation in electronic circuits.
- Peak reverse repetitive voltage rated at 200 volts for robust voltage handling.
- Fast recovery time of 25 nanoseconds minimizes switching losses in power applications.
- Compact 2-pin SOD-123 surface mount package with dimensions 2.6mm length, 1.6mm width, and 0.8mm height.
- Operating temperature ranges from -55°C to a maximum of 150°C suited for demanding environments.
- Maximum forward voltage drop of 980mV enhances efficiency in power rectification.
- Peak non-repetitive forward surge current rating of 20 amperes allows handling transient currents.
- Low peak reverse current of 10mA to reduce leakage in reverse bias condition.
Product Description
ROHM RF081MM2STR Super Fast Recovery Diode is a high-performance semiconductor designed for surface mount applications in power electronics and signal rectification.
Encased in a compact SOD-123 package, this diode offers a maximum continuous forward current of 1 ampere and peak reverse repetitive voltage of 200 volts, making it ideal for compact circuit designs requiring efficient fast recovery capabilities.
The diode features a peak reverse recovery time of 25 nanoseconds, which significantly reduces switching losses and improves system efficiency in power switching and inverter applications.
With operating temperature capability from -55°C to 150°C, the RF081MM2STR diode provides high reliability in harsh industrial, automotive, and consumer electronics environments.
Its maximum forward voltage drop of 980mV reduces power dissipation, while the peak non-repetitive forward surge current rating of 20 amperes enables it to withstand transient power surges.
The device's compact 2-pin SOD-123 surface mount configuration allows for dense PCB layouts and automated assembly processes. Maximum continuous forward current of 1 ampere. Peak reverse repetitive voltage of 200 volts. Fast recovery time of 25 nanoseconds.
SOD-123 surface mount package dimensions: 2.6 x 1.6 x 0.8 mm. Operating temperature range -55°C to 150°C. Maximum forward voltage of 980 millivolts. Peak non-repetitive forward surge current of 20 amperes. Low peak reverse current of 10 milliamperes.
This diode is suitable for applications in power supply rectification, inverter circuits, automotive electronics, and industrial control equipment where fast switching and low loss characteristics are required.
Explore more semiconductor components and fast recovery diodes at EnvMart for efficient design and production.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the RF081MM2STR diode is 1 ampere.
This model has a peak reverse repetitive voltage rating of 200 volts.
The diode features a fast recovery time of 25 nanoseconds, which helps minimize switching losses.
The dimensions of the SOD-123 package are 2.6mm in length, 1.6mm in width, and 0.8mm in height.
The operating temperature range for the RF081MM2STR is from -55°C to a maximum of 150°C.
The maximum forward voltage drop is 980 millivolts, which enhances efficiency in power rectification.
The peak non-repetitive forward surge current rating is 20 amperes, allowing it to handle transient currents.
The peak reverse current is 10 milliamperes, which helps reduce leakage in reverse bias conditions.
This diode has a pin count of 2, suitable for surface mount applications.
It is suitable for applications in power supply rectification, inverter circuits, automotive electronics, and industrial control equipment.
This model is classified as a fast recovery rectifier, designed for efficient switching.
The country of origin for the RF081MM2STR diode is India.
