TDK B82477-G4 Shielded Wirewound Surface Mount Inductor with Ferrite Core 22μH ±20% 3.6A IDC B82477G4223M000
Specifications
| Country of Origin | India |
|---|---|
| Brand | TDK |
| Height | 8mm |
| Length | 12.8mm |
| Model | B82477G4223M000 |
| Depth | 12.8mm |
| Packaging | Tape & Reel |
| Series | B82477-G4 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Ferrite |
| Inductance | 22μH |
| Standards/Approvals | RoHS |
| Maximum DC Current | 3.6A |
| Pin Count | 2 |
| Maximum DC Resistance | 38mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Solder |
| Inductor Construction | Wirewound |
Key Features
- This inductor features a magnetically shielded ferrite core with enamel copper wire winding soldered to terminals.
- It is moulded and designed for surface mount applications with a solder termination style.
- Operating temperature ranges from -55°C to 125°C, suitable for demanding environments.
- Complies with RoHS standards ensuring lead-free and environmentally safe material usage.
- The component has 2 pins and comes packaged on tape and reel for efficient automated assembly.
- Its length is 12.8 mm, height is 8 mm, and depth is 12.8 mm, optimized for PCB layouts.
- Maximum DC resistance is 38 milliohms, supporting efficient current flow with minimal loss.
Product Description
TDK B82477G4223M000 is a shielded wirewound surface mount inductor featuring a magnetically shielded ferrite core and enamel copper wire winding. This inductance device offers a nominal value of 22 μH with a tolerance of ±20%, designed to handle up to 3.6 A DC current safely.
Built for high reliability, it has a solder termination style suitable for surface mounting on printed circuit boards. The inductor is moulded to protect internal windings, enhancing durability under mechanical stress and environmental conditions.
The operating temperature range spans from -55°C to 125°C, allowing it to perform reliably in automotive electronics, power supply filtering, and DC-DC converter circuits. The RoHS compliance guarantees the use of lead-free materials, supporting environmental and safety standards.
Physical dimensions include a length and depth of 12.8 mm and a height of 8 mm. It features a maximum DC resistance of 38 milliohms, minimizing power loss and heat generation during operation. The device comes with 2 pins for electrical connectivity and is supplied on tape and reel packaging to facilitate efficient automated manufacturing processes.
This inductor uses a ferrite core combined with wirewound construction for high inductance stability. Its magnetically shielded design reduces electromagnetic interference in sensitive electronic applications. The component supports automotive standards and industrial use cases where robust performance is crucial.
Ideal for use in industrial electronics, telecommunications, automotive, and consumer electronics devices. Packaging on tape and reel enhances insertion efficiency in high-volume PCB assembly lines. Explore more high-quality Surface Mount Inductors from TDK in the Electronics & Electricals category at EnvMart to meet your industrial and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 22μH with a tolerance of ±20%.
The maximum DC current rating for this inductor is 3.6A.
The inductor has a length and depth of 12.8 mm and a height of 8 mm.
The maximum DC resistance is 38 milliohms, which helps minimize power loss during operation.
The operating temperature range for this inductor is from -55°C to 125°C.
This inductor features a ferrite core, which contributes to its inductance stability.
It comes packaged on tape and reel, facilitating efficient automated assembly processes.
The termination style of this model is solder, suitable for surface mounting on printed circuit boards.
Yes, it complies with RoHS standards, ensuring the use of lead-free materials.
This inductor is suitable for use in automotive electronics, power supply filtering, and DC-DC converter circuits.
This model has 2 pins for electrical connectivity.
It features a wirewound construction, enhancing its performance and reliability.
