Nexperia Bipolar PNP Transistor PZT2907A,115 -600 mA, -60 V, 4-Pin SOT-223 Surface Mount PZT2907A,115

Nexperia PZT2907A,115 Bipolar PNP Transistor is a high-performance discrete semiconductor device designed for general-purpose switching and amplification applications. It features a maximum DC collector current of -600 mA and a collector-emitter voltage of -60 V, making it suitable for medium power electronics.

This transistor comes in a surface mount 4-pin SOT-223 package that facilitates easy PCB integration and effective heat dissipation. It offers a minimum DC current gain (hFE) of 100 and can operate reliably over a wide temperature range from -65°C to 150°C, meeting industry demands for durability in industrial and automotive environments.

With a maximum power dissipation rating of 1.15 watts and a high transition frequency of 200 MHz, the PZT2907A,115 transistor supports both power and high-frequency applications including amplification in audio circuits, switching in power supplies, and automotive electronic systems.

Certified as RoHS compliant, this device aligns with environmental regulations by excluding hazardous substances. Its AEC-Q101 automotive standard approval underscores its design robustness and suitability for automotive electronics, ensuring quality and longevity under challenging conditions.

Dimensions of the transistor are compact, with a height of 1.65 mm, length of 6.5 mm, and width of 3.5 mm. The maximum collector base voltage of 60 V and maximum emitter base voltage of 5 V promote stable operation under varying electrical conditions.

Ideal for applications in industrial controls, consumer electronics, automotive modules, and general-purpose electronic design, this Nexperia bipolar PNP transistor is a reliable component choice for engineers and designers.

The package contains one Nexperia PZT2907A,115 transistor in a 4-pin SOT-223 surface mount format, ready for integration in your electronic assembly or system design projects. Explore more Bipolar Transistors and semiconductor components at EnvMart for varied industrial and scientific applications.

Maximum DC collector current is -600 mA, ensuring adequate current handling for general-purpose applications. Collector-emitter voltage rating of -60 V provides robustness under voltage stress. Surface mount package type SOT-223 enables efficient PCB assembly and thermal dissipation.

The transistor polarity is PNP suitable for switching and amplification in electronic circuits. Maximum power dissipation rated at 1.15 W allows for moderate power applications. Minimum DC current gain (hFE) of 100 guarantees sufficient amplification efficiency.

Operational temperature range from -65°C to 150°C for reliable functionality in harsh environments. Maximum transition frequency of 200 MHz supports high-frequency circuit designs. Complies with RoHS standards ensuring environmental safety.

Automotive grade AEC-Q101 qualification provides enhanced reliability for automotive applications. Please browse our full catalog for additional products by Nexperia and related transistor devices to suit your specific project requirements.
