TDK Shielded Wirewound Surface Mount Inductor 2.2 μH ±30% 3.25 A Idc 5020 Package VLCF5020T-2R2N2R6-3

TDK VLCF5020T-2R2N2R6-3 is a shielded wirewound surface mount inductor with a ferrite core, providing an inductance of 2.2 μH ±30% and supporting a maximum DC current of 3.25 A. The inductor is housed in a compact 5020 package measuring 5 mm in length, 5 mm in depth, and 2 mm in height, designed for surface mount technology (SMT) with solder termination style.

This component features a high magnetic shield construction, making it highly suitable for power source applications in portable devices including hard disk drives (HDDs), digital video cameras (DVCs), digital still cameras (DSCs), LCD displays, and other DC to DC converters. The shielding effectively reduces electromagnetic interference, enhancing circuit performance.

With the ability to operate reliably between -40°C and 105°C, and a maximum DC resistance of 43 milliohms, it offers efficient current handling and thermal tolerance for demanding electronic environments. The product conforms to RoHS standards, ensuring environmental compliance.

The VLCF series is a professional line of inductor chokes from TDK, engineered to meet the needs of magnetic shield type inductors for power circuits, facilitating improved efficiency and reliability in electronic designs. The package is supplied on tape and reel for automated assembly processes.

Constructed with a ferrite core for effective magnetic shielding. Comes in a 5020 package suitable for surface mount applications. Maximum DC resistance of 43mΩ for efficient current flow. Operational temperature range from -40°C to 105°C.

Termination style is solder for reliable mounting. Wide application in portable DC to DC converters including HDDs, DVCs, and LCD displays. Professional grade VLCF series designed for power circuits requiring magnetic shielding.

This TDK shielded wirewound Surface Mount Inductor is ideal for industrial, communications, consumer electronics, and manufacturing sectors requiring compact, reliable inductors with high current capacity and stable performance. It addresses electromagnetic interference issues effectively and supports robust power management in miniature electronic devices.
