Lattice Semiconductor Complex Programmable Logic Device ispMACH EEPROM 256 Cells, 64 I/O, 7.5 ns, 36 Logic LC4256V-75TN100C

Lattice Semiconductor LC4256V-75TN100C complex programmable logic device ispMACH offers a highly integrated solution with 256 macro cells and 64 user I/Os, suitable for a wide range of electronic designs requiring programmable logic.

This device uses EEPROM technology for memory, supporting re-programmability and in-system programmability which allows updates and reconfiguration while installed. It features 36 logic blocks and operates with propagation delay times as low as 7.5 nanoseconds, ideal for high-speed digital applications.

The chip is housed in a surface-mount TQFP package with 100 pins, dimensions measuring 14 mm length and 1.4 mm height, facilitating compact PCB layouts. Its operating voltage range of 3 V minimum to 3.6 V maximum, combined with an operating temperature range from 0 to 90 degrees Celsius, ensures reliable use in various environmental conditions.

Designed to meet the automotive standard AEC-Q100, this CPLD supports robust functionality for automotive and industrial contexts. The maximum operating frequency reaches 400 MHz, supporting demanding timing requirements.

Additional features include individual output enable control and compliance with key quality standards, enabling dependable control and customization in logic design. Supports in-system programmability for design flexibility.

EEPROM memory type for non-volatile configuration retention. Compact TQFP package with 100 pins supports dense PCB layouts. Wide operating voltage range and temperature rating ensure adaptability. Automotive standard certified for high reliability in vehicles.

High max operating frequency of 400 MHz for fast logic processing. Individual output enable control enhances signal precision.

This product is ideal for use in industrial, automotive, telecommunications, and embedded system designs needing programmable logic solutions. Explore other semiconductor and programmable logic IC products to find compatible components for your application.
