Vishay Single Layer Ceramic Capacitor 330 pF 440V AC ±10% Y5S Dielectric AY2 Series Through Hole Radial AY2331K29Y5SS63L7
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 440V ac |
| Diameter | 7.5mm |
| Brand | Vishay |
| Height | 10.5mm |
| Length | 5mm |
| Model | AY2331K29Y5SS63L7 |
| Width | 5mm |
| Mount Type | Through Hole |
| Series | AY2 |
| Maximum Operating Temperature | 125°C |
| Tolerance | ±10 % |
| Capacitance | 330pF |
| Minimum Operating Temperature | -55°C |
| Terminal type | Radial |
| Dissipation Factor | 2.5% |
| Standards/Approvals | DIN EN 60384-14, IEC 60384-14, CSA, RoHS |
| Pin Count | 2 |
| Dielectric | Y5S |
| Suppression Class | Y2/X1 |
Key Features
- Rated for 125°C maximum operating temperature ensuring high reliability.
- Tolerance of ±10% for precise capacitance control.
- Through hole mount type with radial terminal leads for secure PCB mounting.
- Constructed with Y5S dielectric class offering stable electrical characteristics.
- Complies with IEC 60384-14 safety standard and supports industrial applications.
- Suitable for AC line filtering, on-board chargers, and battery management systems.
- Features 2 pins and a dissipation factor of 2.5% at rated voltage.
Product Description
Vishay AY2331K29Y5SS63L7 single layer ceramic capacitor is a precision passive component designed for AC line rated applications and demanding industrial environments. Rated at 330 pF capacitance and 440V AC voltage with a tolerance of ±10%, it utilizes a Y5S dielectric material that balances performance and cost.
The AY2 series capacitor features through hole mounting with radial terminals, facilitating easy and stable PCB assembly. It supports a maximum operating temperature of 125°C, allowing it to withstand harsh thermal conditions common in automotive and industrial electronics.
This capacitor conforms to international safety standards including DIN EN 60384-14, IEC 60384-14, and CSA. It is RoHS compliant and tested to meet stringent automotive quality standards, suitable for on-board chargers, battery management systems for electric and hybrid vehicles, and high-quality industrial applications requiring reliable AC line filtering.
Physically, it measures 10.5 mm in height, 7.5 mm in diameter, with a base size of 5 mm by 5 mm assuring compact yet robust construction. The device has a dissipation factor of 2.5% ensuring efficient operation within circuit parameters.
The capacitor features stable capacitance characteristics under thermal and stress cycling. Its AY2 series design incorporates the latest ceramic material technologies for improved longevity. Application versatility includes automotive electronic systems and industrial power supplies.
It is qualified to endure over 2000 temperature cycles without failure, exceeding AEC-Q200 standards. Lead configuration and radial terminations guarantee durability and ease of installation.
With a proven track record for reliability, this capacitor is a trusted choice for engineers designing power conditioning and noise suppression components in sensitive electronic systems. Explore the full Vishay AY2 series for varied capacitance values and application needs on EnvMart.
Explore more products in our Single Layer Ceramic Capacitors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance of this model is 330 pF.
It has a maximum voltage rating of 440V AC.
This capacitor measures 10.5 mm in height and 7.5 mm in diameter, with a base size of 5 mm by 5 mm.
It features a through hole mount type with radial terminal leads for secure PCB mounting.
The operating temperature range is from -55°C to a maximum of 125°C.
It utilizes a Y5S dielectric material, which offers stable electrical characteristics.
The tolerance of this capacitor is ±10%.
The dissipation factor at rated voltage is 2.5%.
It complies with DIN EN 60384-14, IEC 60384-14, and CSA standards.
This model features 2 pins.
It is suitable for AC line filtering, on-board chargers, and battery management systems.
The country of origin for this capacitor is India.
