RS PRO Single Layer Ceramic Capacitor 1 nF 2kV dc ±10 % LR Dielectric, Through Hole Mount, 125 °C Max Operating Temp 180-4818
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 2kV dc |
| Diameter | 10.5mm |
| Brand | RS PRO |
| Length | 20mm |
| Model | 180-4818 |
| Packaging | Bulk |
| Mount Type | Through Hole |
| Maximum Operating Temperature | 125°C |
| Tolerance | ±10 % |
| Capacitance | 1nF |
| Minimum Operating Temperature | -25°C |
| Terminal type | Solder |
| Standards/Approvals | RoHS, UL 94 V-0 |
| Pin Count | 2 |
| Dielectric | LR |
Key Features
- Constructed for reduced heat dissipation due to low ceramic material loss.
- Operates reliably up to a maximum temperature of 125 °C.
- Coated with flame-retardant epoxy resin for enhanced safety.
- Halogen-free product suitable for environmentally conscious designs.
- Ideal for high frequency pulse circuits including horizontal resonance for CTV and snubber circuits in switching power supplies.
- Manufactured with RoHS and UL 94 V-0 compliance.
- Terminals designed for solder mounting ensuring secure installation.
- Available in bulk packaging for large-scale assembly.
Product Description
RS PRO 180-4818 is a high quality single layer ceramic capacitor rated at 1 nF capacitance and a voltage withstand of 2kV dc, made with LR dielectric material. This through hole mount capacitor boasts a tolerance of ±10 % and operates safely within a temperature range up to 125 °C.
Its design ensures reduced heat dissipation attributed to the low loss ceramic construction, making it an excellent choice for demanding electronic applications. The capacitor is coated with a flame-retardant epoxy resin that enhances reliability and safety in operation.
This component is halogen-free, suitable for environmentally friendly electronics manufacturing processes. It is ideal for use in high frequency pulse circuits like the horizontal resonance circuits found in cathode ray tubes (CTV) and snubber circuits used in switching power supplies.
Certified with RoHS and UL 94 V-0 standards, it confirms compliance with industry environmental and safety norms. The 2-pin through hole mounting type with solder terminals ensures robust mechanical and electrical connections in PCB assemblies.
The physical dimensions include a length of 20 mm and a diameter of 10.5 mm, making it compatible with various standard PCB layouts. It is manufactured in Taiwan, Province Of China, assuring quality manufacturing standards.
Low heat dissipation due to ceramic dielectric material. Maximum operating temperature of 125 °C for reliable performance. Flame-retardant epoxy coated for enhanced safety. Halogen free and RoHS compliant for environmental standards.
Designed for high frequency pulse and snubber circuit applications. Through hole mount with solder terminals for secure PCB mounting. Complies with UL 94 V-0 safety standard. Bulk packaging suitable for industrial assembly.
This RS PRO single layer ceramic capacitor is suitable for usage in electronics, electrical, industrial manufacturing, and power supply systems. Its robust design and high voltage rating make it a valuable component in demanding industrial and commercial circuits.
Browse through EnvMart's range of electronic passive components for more capacitors and other electronics essentials.
Explore more products in our Single Layer Ceramic Capacitors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance of 1 nF.
It is rated for a maximum voltage of 2kV dc.
The maximum operating temperature is 125 °C.
This unit uses a through hole mounting type with solder terminals.
It has a length of 20 mm and a diameter of 10.5 mm.
The tolerance is ±10 %.
It is made with LR dielectric material.
Yes, it is RoHS and UL 94 V-0 compliant.
The minimum operating temperature is -25 °C.
It is available in bulk packaging suitable for large-scale assembly.
It is ideal for high frequency pulse circuits and snubber circuits in switching power supplies.
This capacitor is manufactured in Taiwan.
