Toshiba Surface Mount AC Input Photocoupler Transistor Output 4-Pin SO TLP3906(TPL,E(O

Free Delivery in India | Lowest Global Shipping Charges

Toshiba Surface Mount AC Input Photocoupler Transistor Output 4-Pin SO TLP3906(TPL,E(O

Name: Toshiba Surface Mount AC Input Photocoupler Transistor Output 4-Pin SO TLP3906(TPL,E(O
Brand: Toshiba
SKU: 174549
Price: 1.95 USD
Availability: InStock



Category Optocouplers Brand Toshiba Condition New

Specifications

Country of Origin	India
Brand	Toshiba
Model	TLP3906(TPL,E(O
Mount Type	Surface
Output type	Transistor
Series	TLP
Maximum Operating Temperature	125°C
Package Type	SO
Minimum Operating Temperature	-40°C
Maximum input current	30mA
Number Of Channels	1
Standards/Approvals	UL, RoHS, cUL, CSA, VDE
Maximum Forward Voltage	1.8V
Number of Pins	4
Input Current Type	AC

Key Features

Features a maximum forward voltage of 1.8V for the infrared LED input.
Supports a maximum input current of 30mA AC, ensuring robust operation.
Operates reliably within a temperature range from -40°C to 125°C.
Offers high isolation voltage rated at 3750 Vrms for secure electrical separation.
RoHS-compliant with safety approvals including UL, cUL, CSA, and VDE.
Photodiode array connected in series optimized for MOS gate driving.
Compact 4-pin SO surface mount package suitable for automated PCB assembly.

Product Description

Toshiba TLP3906(TPL,E(O is an advanced AC input photocoupler designed for industrial and electronic circuit applications, featuring a surface mount 4-pin SO package. It integrates an infrared LED optically coupled to a photodiode array connected in series, delivering transistor output ideal for MOS gate drive tasks.

This photocoupler supports a maximum forward voltage of 1.8V on the input LED and is rated for a maximum input AC current of 30mA, ensuring effective signal isolation while maintaining performance under demanding conditions. The device operates across a wide temperature window from -40°C up to 125°C, making it suitable for rigorous industrial, automotive, and commercial electronics environments.

The TLP3906 offers a high isolation voltage of 3750 Vrms, providing secure electrical isolation between input and output stages to protect sensitive circuits from voltage surges and noise. This device complies with multiple international safety and environmental standards including UL, cUL, CSA, RoHS, and VDE certifications, confirming its reliability and eco-friendliness.

Maximum forward voltage of 1.8V on the input LED. Maximum input current of 30mA AC for robust operation. Isolation voltage rating of 3750 Vrms ensuring electrical safety. Wide operational temperature range from -40°C to 125°C.

Surface mount 4-pin SO package compatible with automated assembly. Compliance with UL, cUL, CSA, RoHS, and VDE standards. Optimized for MOS gate drive applications with serially connected photodiode array.

This component is widely used in power supplies, signal isolation circuits, and industrial control systems where high voltage isolation and reliable switching are paramount. Its compact surface mount form factor enables space-saving designs in printed circuit boards.

Choose Toshiba TLP3906(TPL,E(O for dependable photocoupler performance in your electronic designs, backed by Toshiba's quality and extensive support. Explore additional Toshiba electronic components and Optocouplers at EnvMart to meet your industrial and commercial electronics requirements efficiently.
